频率范围：
PM-SA-20：10MHz ~ 20GHz
PM-SA-40：10MHz ~ 40GHz
PM-SA-67：10MHz ~ 67GHz (Pre-release)
PM-SA-110：10MHz ~ 110GHz (Pre-release)
输出功率：-25dBm - +15dBm
相位噪声（偏移 10kHz）：
正常相位噪声模式：
0.5GHz：≤ -131dBc/Hz
1GHz：≤ -125dBc/Hz
2.5GHz：≤ -113dBc/Hz
5GHz：≤ -108dBc/Hz
10GHz：≤ -102dBc/Hz
20GHz：≤ -96dBc/Hz
低相位噪声模式：
0.5GHz：≤ -139dBc/Hz
1GHz：≤ -137dBc/Hz
2.5GHz：≤ -125dBc/Hz
5GHz：≤ -120dBc/Hz
10GHz：≤ -113dBc/Hz
20GHz：≤ -108dBc/Hz
控制方式：以太网接口 / 蓝牙 / USB/WIFI
| Frequency Range | PM-SA-20 | 10MHz ~ 20GHz |
| PM-SA-40 | 10MHz ~ 40GHz | |
| PM-SA-67 | 10MHz ~ 67GHz (Pre-release) | |
| PM-SA-110 | 10MHz ~ 110GHz (Pre-release) | |
| Step (kHz) | 1 | |
| Switching Time (uS) | ≤200 | |
| Output Level | -25dBm-+15dBm | |
| Power Step (dB) | 0.1 | |
| Output Power Stability (dB) | ±0.5 (0 ~ +40V); | |
| ±1.5 (0 ~ +40V); | ||
| Output Power Accuracy (dB) | ±1.5 ( < 0dBm ) | |
| ±0.5 ( > 0dBm ) | ||
| Frequency Temperature Stability | ±0.3ppm (Synchronous external reference) | |
| Frequency Accuracy | ±0.3ppm (Synchronous external reference) | |
| Spurious (dBc) ★ | -65 (Typical) | |
| Harmonics (dBc) ★ | 10MHz to < 3GHz : ≤-30 | |
| ≥3GHz: ≤-40 | ||
| Operating Temperature (℃) | -40 ~ +85 | |
| Storage Temperature (℃) | -55 ~ +95 | |
| Modulation Depth ★★ | ≥60dBc |
| Pulse Modulation Width | 100ns ~ 10ms |
| Pulse Cycle | 500ns ~ 10ms |
| Pulse Up Edge / Down Edge | 30nS/50nS |
| Phase Noise | 0.5GHz | 1GHz | 2.5GHz | 5GHz | 10GHz | 20GHz |
|---|---|---|---|---|---|---|
| dBc/Hz@10Hz | ≤-79 | ≤-73 | ≤-64 | ≤-58 | ≤-52 | ≤-46 |
| dBc/Hz@100Hz | ≤-109 | ≤-103 | ≤-94 | ≤-88 | ≤-82 | ≤-76 |
| dBc/Hz@1kHz | ≤-121 | ≤-115 | ≤-103 | ≤-98 | ≤-92 | ≤-86 |
| dBc/Hz@10kHz | ≤-131 | ≤-125 | ≤-113 | ≤-108 | ≤-102 | ≤-96 |
| dBc/Hz@100kHz | ≤-133 | ≤-127 | ≤-117 | ≤-111 | ≤-105 | ≤-99 |
| dBc/Hz@1MHz | ≤-138 | ≤-135 | ≤-130 | ≤-120 | ≤-110 | ≤-103 |
| dBc/Hz@10MHz | ≤-148 | ≤-145 | ≤-145 | ≤-145 | ≤-135 | ≤-129 |
| Phase Noise | 0.5GHz | 1GHz | 2.5GHz | 5GHz | 10GHz | 20GHz |
|---|---|---|---|---|---|---|
| dBc/Hz@10Hz | ≤-91 | ≤-85 | ≤-76 | ≤-70 | ≤-64 | ≤-58 |
| dBc/Hz@100Hz | ≤-121 | ≤-115 | ≤-106 | ≤-100 | ≤-94 | ≤-88 |
| dBc/Hz@1kHz | ≤-133 | ≤-127 | ≤-115 | ≤-110 | ≤-103 | ≤-98 |
| dBc/Hz@10kHz | ≤-139 | ≤-137 | ≤-125 | ≤-120 | ≤-113 | ≤-108 |
| dBc/Hz@100kHz | ≤-143 | ≤-139 | ≤-129 | ≤-123 | ≤-117 | ≤-111 |
| dBc/Hz@1MHz | ≤-148 | ≤-145 | ≤-143 | ≤-132 | ≤-122 | ≤-115 |
| dBc/Hz@10MHz | ≤-155 | ≤-155 | ≤-152 | ≤-150 | ≤-145 | ≤-139 |
厂家联系方式：
成都市金天之微波科技有限公司
电话: +86（028）85590623
E-mail: sales@chip-array.com
地址: 成都市武侯区西部智谷D区6栋一单元7楼
