E4362A 模块 600W|是德科技 (在产)
参考价格 ：
产品描述
详细指标
软件和手册|白皮书
购买渠道
选件
问大家
视频
测评
口碑
系统与解决方案
是德科技|KEYSIGHT
太阳阵模拟器直流模块，130 V，5 A，600 W
模块化直流电源
产品简介
Keysight E4362A 是一款 600 W 太阳能电池阵列模拟器直流电源模块，用于模拟太阳能电池阵列的输出特性。E4362A 主要是一个电流源，具有极低的输出电容
核心参数
• 每路最大电流：5 A
• 最大功率：600 W
• 每路最大电压：130 V
• 输出路数：1
• 前面板连接：否
• 类型：SAS/2U
• 高度：2U
• 回馈功率：否
• 任意波形发生：否
• 测量精度：—
• 噪声与纹波：195 mVpp
• 输出响应时间：—
• 编程精度：147 mV
• 命令处理时间：1 ms
• 应用：Photovoltaic testing
功能特性
• 输出额定值（模拟器和表格模式）
最大功率：600 W
V oc 最大值：130 V
I sc 最大值：5 A
• 输出额定值（固定模式）
最大功率：600 W
V 额定：0-120 V
I 额定：0-5 A
• 22 °C ± 5 °C 时的编程精度
电压（固定模式）：0.075% + 20 mV
电流（固定模式）：0.2% + 10 mA
• 纹波与噪声（20 Hz 至 20 MHz）
电压 rms，p-p（模拟器/表格模式）：24 mV rms，195 mV p-
电压 rms，p-p（固定模式）：24 mV rms，150 mV p-
电流 rms，p-p（固定模式）：2.5 mA rms，19 mA p-
Keysight E4362A 是一款 600 W 太阳能电池阵列模拟器直流电源模块，可模拟太阳能电池阵列的输出特性。
E4362A 主要是一个电流源，输出电容非常低。
它提供快速的 I-V 曲线变化，使您能够准确模拟不同太阳能电池阵列在各种环境条件下（例如温度、老化、日食、自旋等）的输出。
E4360 为您提供两种操作方式的灵活性：
输入 SAS 内部生成太阳能电池阵列 I-V 曲线所需的四个关键运行参数（V oc、Isc、V mp、I mp）。
下载用户定义的太阳能电池阵列 I-V 曲线表格。
此模块与 Keysight E4360A 模块化太阳能电池阵列模拟器（SAS）主机配合使用，
该主机最多可容纳两个模块，其 2U 高度尺寸可节省机架空间。
LAN、USB 和 GPIB 接口为标准配置。
为简化测试系统软件开发，每个 E4360A SAS 主机均免费附带 14360A 系统控制工具软件包。
该软件简化了多个 SAS 的编程和控制。
它允许通过单个函数调用在 SAS 系统中设置和控制多达 100 个 E4360 输出。
E4360 SAS 可作为独立的现成仪器使用，
也可从 Keysight 获得集成到完整交钥匙太阳能电池阵列模拟器系统中的版本，该系统根据您的确切规格配置，
所有仪器和软件均已集成并安装。
资源下载
以上内容与指标均取自是德科技（KEYSIGHT）官网该产品详情页与官方产品资料，未标注口径的为厂家公布值。
是德科技|KEYSIGHT · onetest 仪器资源库
是德科技 | KEYSIGHT
E4362A 模块 600W 详细指标
Modular Module DC Power Supplies
一、规格规格
Satellite test applications
条件：conditions (temperature, irradiation) and operational conditions (eclipse, spin), a specialized power supply such as the solar array simulator (SAS) must be used for
Solar panels consisting of multiple solar cells provide power to satellites. They have unique I-V characteristics. Since the output power varies with environmental
making accurate tests and veryifying the satellite power system.
Residential photovoltaic (PV) test applications
条件：Solar panels are also used in residential power systems to provide power to homes.
array simulator is used to verify that the microinverter will track the maximum power point under various environmental conditions (such as sunny conditions,
cloudy conditions, shadowing, and different temperatures) and to ensure that the microinverter is reliable and efficient.
Each solar panel output can be connected to a microinverter that converts the DC solar panel output into AC for use in the home. To test microinverters, a solar
As the trend moves toward higher power solar panels and more efficient inverters, there is a need for a specialized DC power source that is reliable, repeatable,
scalable, cost effective, and available off the shelf
条件：racy and efficiency of the device to gain competitive advantage in the marketplace.
Satellite manufacturers need to verify the design of the power bus regulator on the ground. Microinverter and DC power optimizer designers need to verify accu -
Keysight Solar Array Simulator
条件：SAS is primarily a current source with very low output capacitance and is capable of quickly simulating the I-V curve of different arrays under different conditions
(ex. temperature, age etc.). It provides up to 2 outputs and up to 1200 W in a small 2U-high mainframe.
The Keysight Technologies, Inc. E4360
Modular Solar Array Simulator (SAS) is a dual output programmable dc power source that simulates the output characteristics of a solar array. The E4360
Whether you build your own test system requiring instrument only or if you want a full turn-key system with all the instruments and software integrated and
installed – Keysight gives you the flexi - bility you need. The E4360 SAS is readily available as an off-the-shelf instrument and also is available from Keysight
integrated into a full turn-key solar array simulator system configured to your exact specification.
02 | Keysight | Modular Solar Array Simulators - Data Sheet
Multiple simulation modes
The E4360 SAS provides three operating
modes, Simulator (SAS), Table and Fixed modes. To accurately simulate the I-V cure of a solar array, use SAS or table modes. When a standard power supply is
needed, use fixed mode.
1. SAS mode
The E4360 SAS internally generates a
4,096 I-V point table. An internal algo -
Fixed mode
I
V
Figure
2. Power supply output characteristic in
Vmp VOC
条件：while those stored in volatile memory will be erased after power is removed.
Additionally, current and voltage offsets can be applied to the selected table to simulate a change in the operating conditions of the solar array.
3. Fixed mode
V
I
Figure
1. Power supply output characteristic in
SAS mode
2. Table mode
The I-V curve is determined by a user-de - fined table of points. A table can have a minimum of 3 points, up to a maximum of 4000 points. A point corresponds to a
specific value of I and V. As many as
30
tables may be stored in each of the E4360
SAS built-in volatile and non-volatile memory. The tables (I-V curve) stored in this non-volatile memory will be retained when the power is turned off,
This is the default mode when the unit is powered on. The unit has the rectangular
Fast I-V curve changes
条件：enable better simulation of solar arrays under various environmental conditions, like eclipse and spin. The resolution of the
I-V curve can be set to optimize the I-V curve for resolution or fast curve change.
The E4360 offers fast curve changes to
In simulation (SAS) mode and table mode, you can select high resolution which uses a
4,096 point table to generate a smoother
I-V curve within
350 msec. For fast I-V
curve generation, you can select the
256
point table that quickly generates an
I-V curve within
30 msec. All the E4360
SAS in the system can be synchronized to change their I-V curves at the same time using the hardware trigger, such that I-V curves can be changed on up to
100 outputs within
30 msec or 350 msec
based on resolution setting.
03 | Keysight | Modular Solar Array Simulators - Data Sheet
I-V curve list
The E4360 offers a LIST mode that lets
you pre-program a LIST of up to 512 I-V
curves. Program up to 512 sets of points,
where each set of points include curve parameters: Voc, Vmp, Isc, and Imp. A dwell time of 30 ms to 33,554 seconds with 1 ms resolution can be specified and the
E4360 SAS will stay (i.e. dwell) at the
set point for the programmed dwell time value. Alternately, the LIST can be paced (advanced to the next set point) by a bus trigger or it can be paced by a trigger
signal which enables synchronization of the LIST with an external event. Utilizing
I-V curve lists speed up test execution by removing the computer I/O from the process and simplifies I-V curve change more easily simulating the solar array
Small size
The Keysight E4360 provides up to
1200 W in a small 2U high
19 inch wide
package. It has side air vents, however
1U
space is required between the instru - ments to retain proper cooling.
Built-in 测量电压和电流
条件：built-in measurement of voltage and current. Measurements can be quickly made on up to 100 outputs in less than 500 msec using the hardware trigger.
The E4360 modules come standard with
Additionally, the E4360 can simultaneously
data log both voltage and current at 10 readings/s.
Figure 3. Built-in ethernet, USB
2.0, and GPIB interfaces enables easy system connections
Protection features
条件：such that a fault condition in one module can be detected within 10 microseconds by other modules so that they can be quickly shut down to avoid hazardous
To safeguard your device from damage, the E4360 module has over-voltage, over-current, and over-temperature protection. The E4360 can be configured
条件：interfaces, giving you the flexibility to use your interface of choice today and in the future. The E4360 is fully compliant with the LXI Class C specification.
The E4360 Modular Solar Array Simulator
comes standard with GPIB
10/100 Base-T
Ethernet LAN interfaces, and USB
2.0
Control from any browser
The built-in web server provides remote access and control of the E4360 via a standard web browser. From the web browser, you can setup, monitor and
operate the E4360 remotely.
Easy parallel operation
条件：as if there is a single channel with twice the output current and power capability.
scales back the available output power to prevent overloading the AC line cord.
Should you need greater output power and current, the E4360 gives you the flexibility to connect similarly rated outputs in parallel. To simplify parallel operation, the
E4360 offers a firmware based feature that
allows it to treat
2 channels as
04 | Keysight | Modular Solar Array Simulators - Data Sheet
a single, synchronized channel. Once configured, all functions (sourcing, programming, measurements, triggering, protection, and status monitoring) behave
Plug high power mainframes into standard AC sockets for quick bench checkout
When you first turn on the E4360A
Modular SAS mainframe, the mainframe automatically senses the voltage available from the AC line. If the AC line voltage is
< 180 Vac, the mainframe automatically
The E4360A will limit the mainframe
output power to 600 W allowing the high
power mainframe to be plugged into any standard outlet. If there is only one module installed then full power will be available from that module. When two
modules are installed, the output power of each module would be cut in half (300
W per module). This is very convenient for initial bench checkout of the SAS. It is also very convenient for test development, which is typically done on the bench when
条件：I-V curve, to take a voltage and current measurement, or to start a data logging.
The E4360 Modular Solar Array Simulator
mainframe has hardware trigger in/ trigger out signals which permit the
E4360 to be synchronized with external
events. For example, all SAS in a system can be synchronized to change their
Figure
4. Keysight E4360A built-in web server
The E4360 comes with both the IVI-COM
driver and the System Control Tools
Keysight
14360A System Control
条件：cost. There are three components of the 14360A System Control Tools: the system driver, the configuration wizard, and the server control.
The
14360A System Control Tools
is a powerful software driver that greatly simplifies the programming and control of a system with multiple E4360A SAS power supplies. It is shipped standard with
every E4360 Modular Mainframe – free of
The system driver
条件：the user’s test application and provides the capability for a single function call to control up to 100 E4360 SAS outputs (50 mainframes).
The
14360 system driver interfaces with
The driver functions provide support for many tasks like configuration measure - ment, and status readback of a system. It enables you to set and measure voltage
and current levels, operating modes (Fixed, SAS, Table), protection levels, SAS mode settings (I sc, Voc, Imp, Vmp) and much more. The driver supports VISA and TCP/
The configuration wizard
条件：a single line of code. Simply specify the instrument search parameters, create module groups and segments, and drag and drop modules to desired segments.
The configuration wizard is a graphical user interface (GUI) that lets you easily search for and configure the layout of the E4360 SAS system without writing
This wizard generates a configuration file used to initialize the system driver.
05 | Keysight | Modular Solar Array Simulators - Data Sheet
Server control
条件：The server control allows access to the system by multiple applications and an internet browser web monitor for viewing the status of the system.
The server control utilizes a client-server model, enabling a remote PC to communicate with the SAS system PC.
Through the use of dual Ethernet cards in the PC running the server control, clients can access the SAS system remotely.
Placing the SAS system on its own private network simplifies system maintenance and new system development allowing system configurations to be duplicated.
The web monitor allows you to remotely monitor your system of E4360s. From any web browser, you can view the overall system driver status, the system layout
along with module measurement and status, and more. It also provides a link - age to the webGUI that is available for an individual E4360 instrument allowing you
The webGUI can be password protected
条件：This is a great tool for monitoring and troubleshooting a system of E4360s.
Figure 5. Keysight
14360A system control tools: configuration wizard
编程语言
The E4360 supports easy-to-use SCPI
Firmware updates
The E4360 firmware is stored in FLASH
ROM and can be easily updated when new features become available. Firmware can be downloaded into the E4360 over GPIB,
LAN, or USB using the supplied firmware update utility program. Firmware updates can be found at
前面板面板
条件：output values on both outputs at the same time. Further, all SAS modes can be programmed and controlled from the front panel.
In addition to full control over its three standard interfaces, the E4360 has a full featured front panel to permit easy manual operation for test prototyping, debugging,
and troubleshooting when used in an ATE system. You can have confidence that the E4360 is working properly because you can view the settings and actual
模拟编程和 monitoring
In fixed mode, the output current can be programmed from zero to full scale by an analog voltage of 0 to –4 V.
06 | Keysight | Modular Solar Array Simulators - Data Sheet
Universal AC input
条件：full output power when a mainframe is configured with two modules, it must be connected to an ac input of ≥ 180 Vac; else output power will be limited to 600 W.
The E4360 has a universal input that
operates from 100-240 Vac
50/60/400 Hz.
There are no switches to set or fuses to change when switching from one voltage standard to another. The ac input employs power factor correction. In order to get
Rack mount kit
The E3460 is easily rack-mounted using
available option
908. This kit provides all
the necessary hardware to rack mount one E4360A mainframe in 2U of rack space. This rack mount kit includes front rack ears and rear supports which take
Custom turn-key system
条件：development time by letting Keysight handle all the system design elements.
Keysight offers an affordable full turn-key solar array simulator system with all the instruments, and software integrated and installed. Save valuable system
This SAS system is built on the E4360
Modular Solar Array Simulator platform making this system
Figure
6. Custom turnkey system
the smallest available on the market. The
条件：USB) for lower cost, easier support, and reduced down time. Keysight will tailor the system to your exact specification.
Contact your local Keysight sales office to learn more about our custom systems.
gives you the flexibility to choose the configuration that best meets your test strategy.
E4360 modular architecture makes it easy
to configure, re-configure, and support this system since modules can be easily moved and replaced. Further the system’s components are made up of commercial-
off-the-shelf instruments, a standard PC and standard interconnectivity (LAN,
Whether you need spares, want to configure the system yourself or want
Keysight to build your system – the E4360
Modification service
While the E4360 Modular Solar Array
Simulator will meet most of your needs,
条件：the design and manufacture of a modified version of standard E4360 SAS models.
SAS are designed, manufactured, tested, to Keysight’s high quality and reliability standards.
Keysight recognizes that these SAS may not match all needs. To better solve your specific problem, Keysight offers a special modification service. This service entails
Typical modifications include changes to the maximum output voltage or current within the power ratings. The modified
While the scope of this service is usually limited to the modification of a standard
SAS, our engineers welcome a discussion to determine the feasibility of meeting your specific requirements. Contact your local
Keysight sales office with your modifica - tion request.
07 | Keysight | Modular Solar Array Simulators - Data Sheet
Output ratings (Simulator and table mode)
Maximum power 510 W 600 W 594 W
594 W
Maximum open circuit voltage (V oc) 65 V 130 V 117 V
120 V
Maximum voltage point (V mp) 60 V 120 V 108 V
110 V
Line voltage
200 V/230 V/240 V
Maximum short circuit current (I sc) 8.5 A 5.0 A 5.5 A
5.4 A
Maximum circuit point (I mp)1 8.5 A 5.0 A 5.5 A
5.4 A
Line voltage
100 V/120 V4
Maximum short Circuit current (I sc) 4.25 A 2.5 A 2.75 A
2.7 A
Maximum current point (I mp)1 4.25 A 2.5 A 2.75 A
2.7 A
输出 ratings (Fixed 模式)
条件：Unless otherwise noted, specifications are warranted over the ambient temperature range of 0 to 40 °C and are
applicable for Fixed, Simulator, and Table modes 1. There is no maximum impedance restriction. The programmed value for Imp can be less than or equal to I sc. 2. In Simulator mode, the output current is related to the readback output voltage by an internal algorithm. In Table mode, the output current is related to the readback output voltage by interpolation between points that are entered by the user.
3. The unit may go out of specification when subjected to RF fields of 3 volts/meter in the frequency range of 26 MHz to 1 GHz.
4. There is no current derating when only one output module is installed in the mainframe.
Minimum impedance (∆V/∆Vl)1 0.25 Ω 1 Ω 1 Ω
1 Ω
Voltage 0 - 60 V 0 - 120 V 0 - 108 V
0 - 110 V
Line voltage
200 V/230 V/240 V
Current 0 - 8.5 A 0 - 5.0 A 0 - 5.5 A
0 - 5.4 A
Line voltage
100 V/120 V4
Current 0 - 4.25 A 0 - 2.5 A 0 - 2.75 A
0 - 2.7 A
Current derating factor (from 40 to 55 °C) 0.11 A /°C 0.069 A/°C 0.069 A/°C
0.068 A/°C
Output voltage ripple & noise (from
20 Hz to 20 MHz with a resistive load, outputs ungrounded, or either output grounded)
Simulator/table mode 20 mVrms 24 mVrms 24 mVrms
24 mVrms
125 mVp-p 195 mVp-p 195 mVp-p
195 mVp-p
Fixed mode (constant voltage) 24 mVrms 30 mVrms 30 mVrms
30 mVrms
150 mVp-p 150 mVp-p 150 mVp-p
150 mVp-p
Programming accuracy
2,3
(@ 23
±5 °C)
Fixed mode voltage 0.075% + 25 mV 0.075% + 50 mV 0.075% + 50 mV 0.075% +
50 mV
Fixed mode current 0.2% + 20 mA 0.2% + 10 mA 0.2% + 11 mA 0.2% +
11 mA
Readback accuracy
3
(from front panel or over GPIB with respect to actual output @ 23
±5 °C)
Voltage 0.08% + 25 mV 0.08% + 50 mV 0.08% + 50 mV 0.08% +
50 mV
+Current 0.20% + 20 mA 0.20% + 10 mA 0.20% + 11 mA 0.20% +
11 mA
−Current 0.35% + 48 mA 0.35% + 24 mA 0.35% + 26 mA 0.35% +
26 mA
Load regulation – fixed mode (change in output voltage or current for any load change within ratings)
Constant voltage 2 mV 2 mV 2 mV
2 mV
Constant current 1 mA 1 mA 1 mA
1 mA
Line regulation – fixed mode (change in output voltage or current for any line voltage change within ratings)
Constant voltage 2 mV 2 mV 2 mV
2 mV
Constant current 1 mA 1 mA 1 mA
1 mA
Performance Specifications for Keysight E4361A and E4362A SAS Modules
08 | Keysight | Modular Solar Array Simulators - Data Sheet
Performance Specifications for Keysight E4361A and E4362A SAS Modules
Output ratings (Simulator and table mode)
Maximum power 498 W 598 W 596 W
552.5 W
Maximum open circuit voltage (V oc) 58 V 108 V 170 V
95 V
Maximum voltage point (V mp) 53.5 V 99.7 V 157 V
87.7 V
Line voltage
200 V/230 V/240 V
Maximum short circuit current (I sc) 9.3 A 6 A 3.8 A
6.3 A
Maximum current point (I mp)1 9.3 A 6 A 3.8 A
6.3 A
Line voltage
100 V/120 V4
Maximum short circuit current (I sc) 4.65 A 3 A 1.9 A
3.15 A
Maximum current point (I mp) 4.65 A 3 A 1.9 A
3.15 A
Minimum impedance (ΔV/ΔVl)1 1 Ω 1 Ω 1.72 Ω
1 Ω
输出 ratings (Fixed 模式)
Voltage 0 - 53.5 V 0 - 99.7 V 0 - 157 V
0 - 87.7 V
Line voltage
200 V/230 V/240 V
Current 0 - 9.3 A 0 - 6 A 0 - 3.8 A
0 - 6.3 A
Line voltage
100 V/120 V4
Current 0 - 4.65 A 0 - 3 A 0 - 1.9 A
0 - 3.15 A
Current derating factor (from 40 to 55 °C) 0.12 A /°C 0.075 A/°C 0.048 A/°C
0.079 A/°C
Output voltage ripple & noise (from
20 Hz to 20 MHz with a resistive load, outputs ungrounded, or either output grounded)
Simulator/table mode 20 mVrms 23 mVrms 32 mVrms
22 mVrms
125 mVp-p 175 mVp-p 250 mVp-p
158 mVp-p
Fixed mode (constant voltage) 24 mVrms 28 mVrms 40 mVrms
27 mVrms
150 mVp-p 150 mVp-p 195 mVp-p
150 mVp-p
Programming accuracy
2,3
(@ 23
±5 °C)
Fixed mode voltage 0.075% + 22 mV 0.075% + 42 mV 0.075% + 65 mV 0.075% +
37 mV
Fixed mode current 0.2% + 22 mA 0.2% + 12 mA 0.2% + 8 mA 0.2% +
15 mA
Readback accuracy
3
(from front panel or over GPIB with respect to actual output @ 23
±5 °C)
Voltage 0.08% + 22 mV 0.08% + 42 mV 0.08% + 65 mV 0.08% +
37 mV
+Current 0.20% + 23 mA 0.20% + 12 mA 0.20% + 8 mA 0.20% +
15 mA
−Current 0.35% + 53 mA 0.35% + 29 mA 0.35% + 19 mA 0.35% +
36 mA
Load regulation – fixed mode (change in output voltage or current for any load change within ratings)
Constant voltage 2 mV 3 mV 3 mV
2 mV
Constant current 1 mA 1 mA 1 mA
1 mA
Line regulation – fixed mode (change in output voltage or current for any line voltage change within ratings)
Constant voltage 2 mV 2 mV 2 mV
2 mV
Constant current 1 mA 1 mA 1 mA
1 mV
09 | Keysight | Modular Solar Array Simulators - Data Sheet
适用型号 E4361A E4362A E4362A-J01 E4362A-J02
Output current ripple & noise (from
20 Hz to 20 MHz with a resistive load, outputs ungrounded, or either output grounded)
Simulator/table mode 4 mArms 4 mArms 4 mArms
4 mArms
32 mAp-p 32 mAp-p 32 mAp-p
32 mAp-p
Fixed mode (constant current) 2.5 mArms 2.5 mArms 3 mArms
3 mArms
19 mAp-p 19 mAp-p 20 mAp-p
20 mAp-p
输出编程范围 (最大值 programmable 值)
Simulator/table mode voltage 0 - 65 V 0 - 130 V 0 - 117 V
0 - 120 V
Fixed mode voltage 0 - 61.5 V 0 - 123 V 0 - 110.7 V
0 - 112.8 V
Line voltage
200 V/230 V/240 V
Current 0 - 8.66 A 0 - 5.1 A 0 - 5.61 A
0 - 5.51 A
Line voltage
100 V/120 V1
Current 0 - 4.33 A 0 - 2.55 A 0 - 2.81 A
0 - 2.75 A
Overvoltage protection 0 - 74 V 0 -140 V 0 -127 V 0
-129 V
Overcurrent limit 0 - 10.6 A 0 - 6.25 A 0 - 6.88 A
0 - 6.75 A
编程分辨率 (average 值)
Voltage 19 mV 37 mV 35 mV
35 mV
Current 2.7 mA 1.6 mA 1.8 mA
1.7 mA
Overvoltage protection 325 mV 600 mV 575 mV
575 mV
Overcurrent limit 46 mA 27 mA 31 mA
30 mA
编程精度
Overvoltage protection 0.65 V 1.2 V 1.1 V
1.1 V
Overcurrent limit 0.5% + 215 mA 0.5% + 125 mA 0.5% + 140 mA 0.5% +
135 mA
Current monitor (referenced to
P common) 1.0% + 130 mA 1.0% + 75 mA 1.0% + 85 mA 1.0% +
81 mA
电流编程
条件：Nominal Input Impedance 20 kΩ 20 kΩ 20 kΩ 20 kΩ
Analog programming 1.0% + 5.5 mA 1.0% + 3.2 mA 1.0% + 3.5 mA 1.0% +
3.4 mA
+Ip to −Ip differential input (0 to full scale) 0 to -4 V 0 to -4 V 0 to -4 V
0 to -4 V
Max. common mode voltage (referenced to +OUT) ±18 V ±18 V ±18 V
±18 V
Drift/temperature stability (change in output over 8 hours under constant load, line, and ambient, following a
30 minute warmup)
Voltage 0.04% + 1 mV 0.04% + 2 mV 0.04% + 2 mV 0.04% +
2 mV
Current 0.1% + 0.85 mA 0.1% + 0.5 mA 0.1% + 0.55 mA 0.1% +
0.54 mA
Temperature coefficients (output change per °C)
条件：Supplemental characteristics are not warranted but are descriptions of typical performance determined either by design or type testing.
1. There is no current derating when only one output module is installed in the mainframe.
Voltage 0.01% + 325 μV 0.01% + 650 μV 0.01% + 650 μV 0.01% +
650 μV
Current 0.025% + 215 μA 0.025% + 125 μA 0.025% + 140 μA 0.025% +
135 μA
Output capacitance < 100 nF < 50 nF < 50 nF <
50 nF
Maximum reverse diode current (with fans running) 8.5 A 5.0 A 5.5 A
5.4 A
Supplemental Characteristics for Keysight E4361A and E4362A SAS Modules
10 | Keysight | Modular Solar Array Simulators - Data Sheet
适用型号 E4361A-J01 E4362A-J03 E4362A-J04 E4362A-J05
Output current ripple & noise (from
20 Hz to 20 MHz with a resistive load, outputs ungrounded, or either output grounded)
Simulator/table mode 4 mArms 4 mArms 4 mArms
4 mArms
32 mAp-p 32 mAp-p 32 mAp-p
32 mAp-p
Fixed mode (constant current) 2.5 mArms 2.5 mArms 2.5 mArms
2.5 mArms
19 mAp-p 19 mAp-p 19 mAp-p
19 mAp-p
输出编程范围 (最大值 programmable 值)
Simulator/table mode Voltage 0 - 58 V 0 - 108 V 0 - 170 V
0 - 95 V
Fixed mode voltage 0 - 54.8 V 0 - 102.2 V 0 - 161 V
0 - 89.9 V
Line voltage
200 V/230 V/240 V
Current 0 - 9.5 A 0 - 6.12 A 0 - 3.875 A
0 - 6.42 A
Line voltage
100 V/120 V1
Current 0 - 4.75 A 0 - 3.06 A 0 - 1.938 A
0 - 3.21 A
Overvoltage protection 0 - 66.7 V 0 - 117.3 V 0 - 181.3 V 0
-103.9 V
Overcurrent limit 0 - 11.6 A 0 - 7.5 A 0 - 4.75 A
0 - 7.9 A
编程分辨率 (average 值)
Voltage 17 mV 31 mV 48 mV
27 mV
Current 3.0 mA 1.9 mA 1.2 mA
2 mA
Overvoltage protection 295 mV 510 mV 785 mV
452 mV
Overcurrent limit 52 mA 32 mA 22 mA
34 mA
编程精度
Overvoltage protection 0.6 V 1.0 V 1.56 V
0.9 V
Overcurrent limit 0.5% + 235 mA 0.5% + 150 mA 0.5% + 100 mA 0.5% +
159 mA
Current monitor (referenced to
P common) 1.0% + 140 mA 1.0% + 90 mA 1.0% + 60 mA 1.0% +
96 mA
Fixed 模式 analog 电流编程
条件：Nominal input impedance 20 kΩ 20 kΩ 20 kΩ 20 kΩ
Analog programming 1.0% + 6 mA 1.0% + 3.9 mA 1.0% + 2.5 mA 1.0% +
4.1 mA
+Ip to −Ip differential Input (0 to full scale) 0 to -4 V 0 to -4 V 0 to -4 V
0 to -4 V
Max. common mode voltage (referenced to +OUT) ±18 V ±18 V ±18 V
±18 V
Drift/temperature stability (change in output over 8 hours under constant load, line, and ambient, following a
30 minute warmup)
Voltage 0.04% + 0.9 mV 0.04% + 1.7 mV 0.04% + 2.6 mV 0.04% +
1.5 mV
Current 0.1% + 0.93 mA 0.1% + 0.6 mA 0.1% + 0.4 mA 0.1% +
630 µA
Temperature coefficients (output change per °C)
Voltage 0.01% + 290 μV 0.01% + 540 μV 0.01% + 850 μV 0.01% +
475 μV
Current 0.025% + 235 μA 0.025% + 150 μA 0.025% + 100 μA 0.025% +
159 μA
Output capacitance < 100 nF < 50 nF < 50 nF <
100 nF
Maximum reverse diode current (with fans running) 9.3 A 6 A 3.8 A
6.3 A
Supplemental Characteristics for Keysight E4361A and E4362A SAS Modules
条件：Supplemental characteristics are not warranted but are descriptions of typical performance determined either by design or type testing.
1. There is no current derating when only one output module is installed in the mainframe.
11 | Keysight | Modular Solar Array Simulators - Data Sheet
适用型号 E4361A E4362A E4362A-J01 E4362A-J02
Output current settling time (output recovery to within 1.5 A of an operating point on the I-V curve (V <
90% of VMP) after switching from a short circuit to a fixed load)
< 5 μs < 5 μs < 5 μs <
5 μs
Maximum capacitive load (for stable operation)
Simulator/table mode 2000 μF 2000 μF 2000 μF
2000 μF
Fixed mode 2000 μF 2000 μF 2000 μF
2000 μF
Load lead drop with remote sensing Simulator/table mode Up to 2 volts +
(Voc - Vmp)
Up to 2 volts +
(Voc - Vmp)
Up to 2 volts +
(Voc - Vmp)
Up to 2 volts +
(Voc - Vmp)
Fixed mode Up to 2 volts
Up to 2 volts
Up to 2 volts
Up to 2 volts
Current sinking capability Simulator/table mode 500 mA 500 mA 500 mA
500 mA
Fixed mode 440 mA 440 mA 440 mA
440 mA
Voltage programming rise/fall time (time for output to change from 90% to 10% or 10% to 90% of its total excursion)
< 8 ms < 8 ms < 8 ms <
8 ms
Voltage programming settling time (time for output change to settle within 0.1% of the rating of the unit; either 60 mV or 120 mV)
25 ms
typical 25 ms typical
25 ms
typical
25 ms typical
Monotonicity Output is monotonic over entire rated voltage, current, temperature
Auto-parallel configuration Up to 4
Up to 4
Up to 4
Up to 4
Series and shunt switching frequency (switching frequency is controlling by a customer-supplied external series or shunt FET connected to the output)
50 kHz
maximum1
50 kHz
maximum1
50 kHz
maximum1
50 kHz
maximum1
Output terminal isolation (maximum, from chassis ground) ±240 Vdc ±240 Vdc ±240 Vdc
±240 Vdc
Recommended calibration interval 1 year 1 year 1 year
1 year
Supplemental Characteristics for Keysight E4361A and E4362A SAS Modules
条件：Supplemental characteristics are not warranted but are descriptions of typical performance determined either by design or type testing.
1. Higher switching frequencies may be possible given the right load conditions consisting of but not necessarily limited to the inductance of
the load cable to the shunt switch and the on/off edge rate of the shunt switch.
12 | Keysight | Modular Solar Array Simulators - Data Sheet
适用型号 E4361A-J01 E4362A-J03 E4362A-J04 E4362A-J05
Output current settling time (output recovery to within 1.5 A of an operating point on the I-V curve (V <
90% of VMP) after switching from a short circuit to a fixed load)
< 5 μs < 5 μs < 5 μs <
5 μs
Maximum capacitive load (for stable operation)
Simulator/table mode 2000 μF 2000 μF 2000 μF
2000 μF
Fixed mode 2000 μF 2000 μF 2000 μF
2000 μF
Load lead drop with remote sensing Simulator/table mode Up to 2 volts +
(Voc - Vmp)
Up to 2 volts +
(Voc - Vmp)
Up to 2 volts +
(Voc - Vmp)
Up to 2 volts +
(Voc - Vmp)
Fixed mode Up to 2 volts
Up to 2 volts
Up to 2 volts
Up to 2 volts
Current sinking capability Simulator/table mode 560 mA 560 mA 400 mA
560 mA
Fixed mode 440 mA 440 mA 340 mA
440 mA
Voltage programming rise/fall time (time for output to change from 90% to 10% or 10% to 90% of its total excursion)
< 8 ms < 8 ms < 8 ms <
8 ms
Voltage programming settling time (time for output change to settle within 0.1% of the rating of the unit; either 60 mV or 120 mV)
25 ms
typical 25 ms typical
25 ms
typical
25 ms typical
Monotonicity Output is monotonic over entire rated voltage, current, temperature
Auto-parallel configuration Up to 4
Up to 4
Up to 4
Up to 4
条件：Supplemental characteristics are not warranted but are descriptions of typical performance determined either by design or type testing.
1. Higher switching frequencies may be possible given the right load conditions consisting of but not necessarily limited to the inductance of
the load cable to the shunt switch and the on/off edge rate of the shunt switch.
Series and shunt switching frequency (switching frequency is controlling by a customer-supplied external series or shunt FET connected to the output)
50 kHz
maximum1
50 kHz
maximum1
45 kHz
maximum1
50 kHz
maximum1
Output terminal isolation (maximum, from chassis ground) ±240 Vdc ±240 Vdc ±240 Vdc
±240 Vdc
Recommended calibration interval 1 year 1 year 1 year
1 year
Supplemental Characteristics for Keysight E4361A and E4362A SAS Modules
13 | Keysight | Modular Solar Array Simulators - Data Sheet
适用型号 E4360A
条件：AC mains Nominal input ratings 100/120/220/240 VAC; 50/60/400 Hz
100/120 VAC note AC mains circuits rated at nominal 100-120 VAC cannot supply enough
output current will be available at nominal 100-120 VAC
Maximum total output power (= sum of total module output power)
1200 W
Input range
86 VAC – 264 VAC
Power consumption
2000 VA (mainframe has power factor correction)
AC line spike ratings
1 kV typical
Fuse 15 A/250 VAC bib-time delay (Keysight p/n
2110-0054)
current to power the E4360A mainframe when two output modules are
installed. In this case, internal circuits will limit the output current of the
modules to one half of their rating. For a single installed module, full
Savable states Memory locations
2 (0 and 1)
Pre-stored state
0
Command processing time ≤
1 ms from receipt of command to start of output change
二、Protection response Specifications
Protection response Specifications · characteristics
INH input
5 µs from receipt of inhibit to start of shutdown
Fault on coupled outputs <
10 µs from receipt of fault to start of shutdown
Interface capabilities GPIB SCPI - 1993, IEEE
488.2 compliant interface
LXI compliance Class C
条件：Environmental conditions Operating environment Indoor use, installation category II (for AC input), pollution degree 2
USB
2.0 Requires Keysight IO Library version M.01.01 and up, or 14.0 and up
10/100 LAN Requires Keysight IO Library version L.01.01 and up, or 14.0 and up
Built-in Web server Requires Internet Explorer 5+ or Netscape
6.2+
Temperature range 0 to 55 °C (current is derated 1% per °C above
40°C ambient temperature)
Relative humidity Up to 95%
Altitude Up to 2000 meters
Storage temperature
–30 to 70 °C
LED statement Any LEDs used in this product are Class 1 LEDs as per IEC
825-1
Keysight E4360A Modular SAS Mainframe
三、补充信息
14 | Keysight | Modular Solar Array Simulators - Data Sheet
适用型号 E4360A
Regulatory compliance EMC Complies with the European EMC directive for Class A test and
measurement products
Complies with the Australian standard and carries the C-Tick mark.
This ISM device complies with Canadian ICES-001.
Cet appareil ISM est conforme à la norme NMB-001 du Canada.
Electrostatic discharges greater than
1 kV near the I/O connectors may cause the
unit to reset and require operator intervention
条件：Safety Complies with the European Low Voltage Directive and carries the CE-marking.
Complies with the US and Canadian safety standards for test and
measurement products
Acoustic noise declaration This statement is provided to comply with the requirements of the German Sound Emission
Directive, from 18 January
1991.
Sound Pressure Lp <
70 dB(A), At Operator Position, Normal Operation
According to EN 27779 (Type Test). Schalldruckpegel Lp
<70 dB(A)
Am Arbeitsplatz, Normaler Betrieb, Nach EN
27779 (Typprüfung).
Dimensions Height
88.1 mm (3.5 in.)
Width
432.5 mm (17.03 in.)
Depth
633.9 mm (24.96 in.)
Net weight Mainframe with 2 modules
38.4 lbs (17.6 kg)
Single output module
7.2 lbs (3.3 kg)
Keysight E4360A Modular SAS Mainframe (Continued)
Supplemental characteristics (continued)
15 | Keysight | Modular Solar Array Simulators - Data Sheet
Outline diagram
16 | Keysight | Modular Solar Array Simulators - Data Sheet
订货信息
条件：products. (See steps below.) Each item will arrive in a separate box so that you can assemble the SAS yourself when you need to.
(2) You can order an E4366A, E4367A, or
The E4360A Modular Solar
Array Simulator (SAS) is available
2 ways: (1) You can order an E4360A mainframe and various modules as separate
E4368A which is a preconfigured SAS that
is shipped as a fully assembled multiple- output SAS. (See page
18 for E4367A and
E4368A ordering information.)
When ordering the E4360 SAS as a
mainframe and modules, follow these steps
Step
1:
Select the E4360A mainframe.
Step
2:
Select the appropriate documentation and line cord options
Step
3:
Order up to 2 modules. Note that each
mainframe has
2 module slots to hold
模块. Each 模块 occupies one 模块 slot
条件：For proper operation, you must fill any empty module slots with a filler panel.
Step
4:
When configuring a mainframe with less than
2 filled module slots, you MUST order a Filler Panel Kit (Option FLR or
E4369A). Each kit contains
1 filler panel to
fill one empty module slot
Step
5:
If you will be rack mounting your E4360
条件：Required for rack mounting. Standard rack mount hardware will not work.
E4360A Modular Solar Array Simulator Mainframe
1200 W
Holds up to 2 modules
Available options to the E4360A mainframe
Opt
908 Rack Mount Kit
Opt FLR Filler Panel Kit
Required when you have only
1 module in a mainframe.
Each filler panel kit contains one filler panel
This filler panel kit is also orderable as product E4369A.
Opt
0L1 Full documentation on CD-ROM and printed Users Guide
Opt
0B0 Full documentation on CD-ROM only. No printed
documentation package
Opt
0L2 Extra copy of standard printed documentation package
Opt
900 Power Cord, United Kingdom
Opt
901 Power Cord, Australia, New Zealand
Opt
902 Power Cord, Europe
Opt
903 Power Cord, USA, Canada – 120 V
Note: The maximum output power is limited to 600 W at
100/120 Vac. To achieve full output power of 1200 W, you
must use option
904 and operate at 220/240 Vac.
Opt
904 Power Cord, USA, Canada – 240 V
Opt
906 Power Cord, Switzerland
Opt
912 Power Cord, Denmark
Opt
917 Power Cord, India
Opt
918 Power Cord, Japan
Opt
919 Power Cord, Israel
Opt
920 Power Cord, Argentina
Opt
921 Power Cord, Chile
Opt
922 Power Cord, China
Opt
923 Power Cord, South Africa
Opt
927 Power Cord, Brazil, Philippine, Thailand
Opt
931 Power Cord, Taiwan
Opt
932 Power Cord, Cambodia
E4361A Solar Array Simulator dc Module 65 V, 8.5 A
510 W
E4362A Solar Array Simulator dc Module 130 V, 5 A
600 W
Available options to the E4360A modules
Opt 1A7 ISO
17025 Calibration Certificate
Opt A6J ANSI/NCSL Z540 Calibration Certificate
Opt UK6 Commercial calibration with test results data
17 | Keysight | Modular Solar Array Simulators - Data Sheet
preconfigured mainframes
These model numbers are preconfigured mainframes that are shipped as a fully tested and assembled instrument. Each system consists of one mainframe and
two modules. The E4367A consists of an
E4360A mainframe and two E4361A low
voltage modules. The E4368A consists of
an E4360A mainframe and two E4362A
high voltage modules. The E4366A
consists of an E4360A mainframe and
If you prefer to purchase a Modular Solar
Array Simulator mainframe and modules as separate pieces, see page
17.
Preconfigured mainframes
条件：Required for rack mounting. Standard rack mount hardware will not work.
E4367A Configured E4360A SAS Mainframe with 2 E4361A Modules
E4368A Configured E4360A SAS Mainframe with 2 E4362A Modules
Available options to the E4367A and E4368A mainframes
Opt
908 Rack Mount Kit
Opt FLR Filler Panel Kit
Required when you have only
1 module in a mainframe.
Each filler panel kit contains one filler panel
This filler panel kit is also orderable as product E4369A.
Opt
0L1 Full documentation on CD-ROM and printed Users Guide
Opt
0B0 Full documentation on CD-ROM only. No printed
documentation package
Opt
0L2 Extra copy of standard printed documentation package
Opt
900 Power Cord, United Kingdom
Opt
901 Power Cord, Australia, New Zealand
Opt
902 Power Cord, Europe
Opt
903 Power Cord, USA, Canada – 120 V
Note: The maximum output power is limited to 600 W at
100/120 Vac. To achieve full output power of 1200 W, you
must use option
904 and operate at 220/240 Vac.
Opt
904 Power Cord, USA, Canada – 240 V
Opt
906 Power Cord, Switzerland
Opt
912 Power Cord, Denmark
Opt
917 Power Cord, India
Opt
918 Power Cord, Japan
Opt
919 Power Cord, Israel
Opt
920 Power Cord, Argentina
Opt
921 Power Cord, Chile
Opt
922 Power Cord, China
Opt
923 Power Cord, South Africa
Opt
927 Power Cord, Brazil, Philippine, Thailand
Opt
931 Power Cord, Taiwan
Opt
932 Power Cord, Cambodia
Available options to the E4367A and E4368A modules
Opt 1A7 ISO
17025 Calibration Certificate
Opt A6J ANSI/NCSL Z540 Calibration Certificate
Opt UK6 Commercial calibration with test results data
相关资料
Keysight E4360 Modular Solar Array
E4360 Modular Solar Array Simulator,
User Guide
14360A System Control Tools, User's
Guide 18 | Keysight | Modular Solar Array Simulators - Data Sheet
19 | Keysight | Modular Solar Array Simulator - Data Sheet
以上指标摘自厂家官方数据手册，完整定义、测试条件与保证值口径以手册为准。完整指标、测试条件与定义口径请见产品页「软件和手册 | 白皮书」栏目中的官方数据手册。
是德科技 | KEYSIGHT · onetest 仪器资源库
全部
是德科技官方渠道
官方渠道（官网 / 热线 / 邮箱）
• 销售服务热线
800-810-0189（座机）／400-810-0189（手机） 工作时间 周一至周五 8:30-17:30
• 热线传真
800-820-2816（座机）／400-820-3863（手机）
• 亚洲区支持邮箱 tm_asia@keysight.com
• 服务与支持邮箱
instruments_services@keysight.com
• 官网
www.keysight.com（中国站 www.keysight.com.cn）
全国办事处
• 北京总部
是德科技（中国）有限公司 北京市朝阳区望京北路3号
电话：(010) 64397888
传真：(010) 64390278
邮编：100102
• 上海分公司
上海市虹口区四川北路1350号中信泰富申虹广场5楼、16-19楼
电话：(021) 36127688
传真：(021) 36127188
邮编：200080
• 广州分公司
广州市天河北路233号中信广场66层07-08室
电话：(020) 38113988
传真：(020) 86695074
邮编：510613
• 深圳分公司
深圳市福田中心区福华一路六号免税商务大厦3楼
电话：(0755) 83079588
传真：(0755) 82763181
邮编：518048
• 成都分公司
成都高新区南部园区天府四街116号
电话：(028) 83108888
传真：(028) 85330830
邮编：610041
• 西安分公司
西安市碑林区南关正街88号长安国际大厦D座5/F
电话：(029) 88867770
传真：(029) 88861330
邮编：710068
• 中国香港
是德科技香港有限公司 中国香港北角电气道169号25楼
电话：(852) 31977777
传真：(852) 25069292 香港热线 800-938-693
• 维修 / 校准服务中心
中国大陆 北京 / 成都 / 苏州 服务热线 800-810-0189 / 400-810-0189
授权分销商
• 上海信果电子科技有限公司（上海）
上海市沪闵路8075号虹梅商务大厦6楼609室
邮编：200233
电话：021-64518399
传真：021-54560890
邮箱：jason.wu@signalgroup.com.tw
• 上海精测电子有限公司（上海）
上海市北京东路668号西楼15E
邮编：200001
电话：13916371522
传真：021-53086102
邮箱：yangzhen@jingce.com
• 北京东方中科集成科技股份有限公司（北京）
北京市海淀区复兴路69号院12号楼2层、7层 邮政编码：100039
邮编：100039
电话：400-650-5566
传真：010-68728001
邮箱：zhangzp@oimec.com.cn
官网：www.dfzk.com/br_keysight.html
• 北京千聚科技发展有限公司（北京）
北京市海淀区西三旗花园雪梨澳乡A区23-4号
邮编：100085
电话：010-82907162
邮箱：zhuqihui@qianjukeji.com.cn
• 北京金龙翌阳科技发展有限公司（北京）
北京市海淀区大柳树路17号富海大厦2001室
邮编：100086
电话：010-62167379/6213538
邮箱：zhy@yy17.com
官网：www.yy17.com
• 厦门同昌源电子有限公司（厦门）
厦门市湖里区悦华路215号综合楼二楼C单元
邮编：361000
电话：0592-5663715
传真：0592-2236795
邮箱：tcydz@xmtcy.com
• 合肥新普仪测科技有限公司（合肥）
安徽省合肥市长江路53号长江大厦1102室
邮编：230001
电话：+86(0551)65177518 ext:
传真：+86(0551)6260 7155
邮箱：hfsimple@mail.hf.ah.cn
• 品展国际贸易(上海)有限公司（上海）
上海外高桥保税区泰谷路18号1号楼1105A室
邮编：200003
电话：+86(0512) 6808 6023
传真：+86(0512) 6808 6025
邮箱：melody@chtek.com.tw
官网：chtek.com.tw
• 广州康祺科技发展有限公司（广州）
广州市天河区华强路1号珠控国际中心8层06单元
邮编：510623
电话：020-38295200
传真：020-38295122
邮箱：baobao@kontchi.com
• 广州科欣仪器有限公司（广州）
广州市黄埔区黄埔大道933号209室
邮编：510700
电话：86-20-38699788
传真：86-20-34395932
邮箱：cs@gzkexin.com.cn
• 成都安诚迅飞电子科技有限公司（成都）
成都市武侯区人民南路四段27号1栋1单元 24层3号
邮编：610041
电话：028-86027579
邮箱：jincai.he@ancentest.com
• 新亚制程（浙江）股份有限公司（深圳）
深圳市福田区中康路卓越城梅林中心广场（北区）一期1栋3楼
邮编：518035
电话：0755-23818536
传真：0755-23818625
邮箱：wangrongbin@sunyes.cn
• 无锡市邦达测量科技有限公司（无锡）
江苏省无锡市新区长江北路112号
邮编：214028
电话：0510-85258521 ext:
邮箱：bdyiqi@bdyiqi.com
• 武汉力德仪测科技有限公司（武汉）
武汉市光谷大道54号国际企业中心四期A座501室
邮编：430074
电话：027-85481090 ext:
邮箱：liuyang@leader-e.com
• 苏州工业园区贝奇仪器有限公司（苏州）
苏州工业园区通园路398号海逸大厦A402室
邮编：215006
电话：0512-62883832
邮箱：szbeiqi@szbeiqi.net
• 青岛鲁芯仪器有限公司（青岛）
青岛市福州北路135号鼎都1号写字楼328室
邮编：266007
电话：15953279543
传真：0532-80669058-830
邮箱：gaochangyuan@qdluxin.com
• Avnet Electronics Marketing（Phoenix）
2211 South 47th Street
邮编：85034
电话：+65 6289 9164
邮箱：Josephine.Cheong@avnet.com
官网：OnlineSupportAsia@Avnet.com
• RFMW, Ltd.（San Jose）
188 Martinvale Lane
邮编：95119
电话：#09-129
邮箱：sales@rfmw.asia
官网：www.rfmw.com
• 沈阳实拓科技有限公司（沈阳）
沈阳市和平区三好街35号8层
邮编：110004
电话：024-23843636
传真：024-23905232
邮箱：lf@shituokeji.cn
• 領先科儀有限公司（香港）
新界荃灣海盛路3號TML廣場21樓B5室
邮编：.
电话：852-31523600
传真：852-31523608
邮箱：allenma@advanceinst.com
租赁合作伙伴
• 深圳君鉴科技股份有限公司（深圳市）
光明街道观光路华强创意产业园3栋B座12楼光明新区
邮编：518107
电话：400-860-3035
邮箱：shichang@chrent.com
• 益莱储（北京）检测设备租赁有限公司（北京市）
来广营高科技产业园区4号楼3层301朝阳区
邮编：100102
电话：400-819-2800
邮箱：jim.chen@electrorent.com
• 北京东方中科集成科技股份有限公司科技租赁事业部（北京市）
北京市海淀区阜成路67号银都大厦12层
邮编：100142
电话：400-650-5566
传真：010-68728001
邮箱：wangml@oimec.com.cn
• 客而禧设备租赁（上海）有限公司（Shanghai）
徐汇区古美路1515号19号楼903室
邮编：201102
电话：021-54453166
邮箱：krc@krcchina.com
• 深圳市瑞普高电子有限公司（深圳市）
天安云谷产业园一期3栋D座1505-1506龙岗区
邮编：518129
电话：0755-29050100
邮箱：rickluo@ruipugao.com
• 苏州锦凡精密仪器科技有限公司（苏州）
苏州市高新区滨河路625号创业大厦5幢505
邮编：215011
电话：18914031336
邮箱：18914031336@jfsz.net
解决方案合作伙伴
• Tokyo Weld Co., Ltd.（Ota-ku）
2-28-1 Kitamagome
邮编：143-0021
电话：81-3-3775-4331
传真：81-3-3775-4359
邮箱：d-imai@tokyoweld.com
• 上海恒榉电子科技有限公司（Shanghai）
上海市奉贤区南桥镇西闸公路1036号3栋2层
邮编：201401
电话：18112779808
邮箱：salesvalue@everise-hj.com
• 佳燁科技股份有限公司(Ghiatek)（桃園市龜山區）
光明街243巷2號
邮编：33372
电话：+886-3-350-9960
传真：+886-3-320-3475
邮箱：support@ghiatek.com
• 华美博科技（北京）有限公司（北京市）
蓝靛厂东路2号金源时代商务中心C座9A2海淀区
邮编：100097
电话：010-88598732
邮箱：sino@sino-microtech.com
• 和创联合科技（北京）有限公司（北京市）
中关村东路18号财智国际大厦A座1612海淀区
邮编：100083
电话：400 650 7802
邮箱：info@hisuntest.com
• 昆山捷得立电子有限公司（昆山市）
登云路288号海创大厦C座25楼
邮编：215316
电话：0512-36831748
邮箱：sales@jiedeli-china.com
• 深圳市捷泰普科技有限公司（深圳市）
宝安区西乡街道前进二路桃源居南面深圳市智汇创新中心A座216室
邮编：518126
电话：0755-83908488
邮箱：sales@jtptech.cn
• 深圳市易捷测试技术有限公司（深圳市）
福虹路9号世贸广场C座1203室福田区
邮编：518033
电话：0755-83698930
邮箱：dongni.zhang@gbit.net.cn
官网：gbit.net.cn
• 深圳市泰仕捷科技有限公司（深圳市）
松岗大道7号汉海达大厦616室宝安区
邮编：518105
电话：0755-27128586
邮箱：riky.gua@tesijet.com
• 深圳市蓉声科技有限公司（深圳市）
福中路海连大厦连天阁 1103 室福田区
邮编：518033
电话：13828880571
邮箱：jiang.qian@radiation-test.com
• 苏州伊欧陆系统集成有限公司（苏州）
星湖街218号生物纳米园A7楼305室苏州工业园区
邮编：215000
电话：4008808776
邮箱：info@eoulu.com
• EM Labs Inc.（Kobe）
1-4-13 Mizukasadori, Nagata
邮编：653-0842
电话：+81-50-5370-0262
邮箱：info@emlabs.jp
• MPI Corporation（Chupei）
No. 155 Chungho Street
邮编：302
电话：+886-3-555-1771
传真：+886-3-551-8381
邮箱：info@mpi-corporation.com
官网：www.mpi-corporation.com/ast
• NOFFZ（Tönisvorst）
Vorster Strasse 238
邮编：47918
电话：+49 2151-99878-0
邮箱：info@noffz.com
• Power Technology Solutions（Santa Clara）
3048 Scott Blvd
邮编：95054
电话：650-308-8091 ext:
传真：408-727-0827
邮箱：inquiries@pwrts.com
• Resillion（Hasselt）
Kempische Steenweg 303
邮编：3500
电话：+32 498 92 01 71
邮箱：global-ci-sales@resillion.com
• Suzhou Link Ways Tech Co., Ltd.（Suzhou）
16F, Block B, Jin Shi Wang Hu Building, No. 18, Jia Rui alley, SIP
邮编：215021
电话：+86 512 6602 8998
• 上海凌测电子科技有限公司（上海）
峨山路91弄120号陆家嘴软件园8号楼401A室浦东新区
邮编：200127
电话：021-61090608
邮箱：yue.lin@merlintest.com.cn
• 上海北汇信息科技有限公司（上海市）
秀路100号虹桥总部1号4号楼3C闵行区紫
邮编：201103
电话：021-34716271
邮箱：info@polelink.com
官网：polelink.com
• 上海怿星电子科技有限公司（上海市）
钦州北路1199号智汇园87号楼5F室徐汇区
邮编：200233
电话：021-64955659
邮箱：biz@e-planet.cn
• 东昇电磁兼容技术(深圳)有限公司（深圳市）
福田中心区26-3路中国凤凰大厦2栋25G
邮编：518026
电话：0755-82792411
邮箱：sales@jstoyo.cn
• 南京派格测控科技有限公司（南京市）
建邺区建邺人才服务大厦16楼
邮编：210019
电话：4008920858
邮箱：sales@pgtec.cn
官网：pgtec.cn
• 南京纳特通信电子有限公司（南京市）
江宁开发区临淮街20号
邮编：210012
电话：025-84471796
邮箱：sales@rflight.cn
• 深圳市研辰科技有限公司（深圳市）
益田路3008号皇都广场C座2815室福田区
邮编：518048
电话：0755-82828703
邮箱：roger_huang@ascentest.com
原厂翻新与二手仪器
• 是德科技原厂二手仪器商城（Keysight Certified Pre-Owned）：www.keysight.com/used/cn/zh/
• 原厂翻新仪器经与新品相同的最终测试与校准，原厂保修最长 5 年；享 40%–90% 折扣，另有线上 5% / 教育 15% 优惠
0条提问
X
提问
X
回答
暂无视频
0条口碑
X
发表口碑
粤公网安备44030902003758
