    DOS 高速 双极性 放大器|松田精密 (在产)

    The DOS series is a four-quadrant bipolar amplifier featuring a high-speed response of DC to 200 kHz (CV mode). When combined with a function generator, it can output various waveforms, including sinusoidal, triangular, sawtooth, 。

    参考价格 ：

    厂家：松田精密|Matsusada Precision Inc. （收录160个产品）

    产地：日本

    点击访问厂家官网

    产品描述
    详细指标
    软件和手册|白皮书
    购买渠道
    选件
    问大家
    视频
    测评
    口碑
    系统与解决方案

    Matsusada Precision Inc. · 放大器

    DOS 高速双极性放大器

    ±2.5 A to ±100 A · 150 W to 2000 W
    产品定位

    The DOS series is a four-quadrant bipolar amplifier featuring a high-speed response of DC to 200 kHz (CV mode). When combined with a function generator,

    it can output various waveforms, including sinusoidal, triangular, sawtooth,

    and rectangular waves. Since the DOS series amplifies external signals accurately,

    it is ideal for diverse simulation tests. It supports both sourcing and sinking operations in Constant Voltage (CV) and Constant Current (CC) modes. Despite its versatility and ultra-high-speed response,

    the unit remains compact. With high-visibility meters and user-friendly operation,

    the DOS series is an excellent choice for applications ranging from R&D laboratories to production lines.

    Note: This product is not designed for charge and discharge of battery. For battery charging and discharging applications,

    please refer to the Battery Cycle Tester product page.

    核心参数
    · ：Model ｜Maximum output
    · ：Voltage；Current；Power
    · DOS20-7.5：±20 V；±7.5 A；150 W
    · DOS20-15：±20 V；±15 A；300 W
    · DOS20-30：±20 V；±30 A；600 W
    · DOS20-60：±20 V；±60 A；1200 W
    · DOS20-100：±20 V；±100 A；2000 W
    · DOS25-6：±25 V；±6 A；150 W
    · DOS25-12：±25 V；±12 A；300 W
    · DOS25-24：±25 V；±24 A；600 W
    功能与特点
    · Suitable for transient response test because of its ultra-high-speed response DC to 200 kHz and high power, maximum 2000 W.
    · DOS series can be used both as a high-speed response DC power supply and as a DC electronic load.
    · A single switch selects between CV and CC modes.
    · For maximum compactness and lightweight, the DOS series has been improved for small footprint and handiness.
    · 3-digit digital meter displays the DC value of the output voltage and current. (The option of rms indication is available.)
    · Protective functions against overvoltage/overcurrent and against output short-circuit are completely provided.
    典型应用
    · 信号放大
    资源下载
    · 本页仅列出核心参数，完整技术指标请见 DOS-specs.html
    Matsusada Precision Inc. · onetest 仪器资源库
    本文由 onetest 仪器资源库依据厂商公开资料整理，参数以厂商正式资料为准。





    Matsusada Precision Inc. · 放大器

    DOS 高速双极性放大器 · 详细指标

    ±2.5 A to ±100 A · 150 W to 2000 W
    产品简介

    The DOS series is a four-quadrant bipolar amplifier featuring a high-speed response of DC to 200 kHz (CV mode). When combined with a function generator,

    it can output various waveforms, including sinusoidal, triangular, sawtooth,

    完整技术指标
    · ：Model ｜Maximum output
    · ：Voltage；Current；Power
    · DOS20-7.5：±20 V；±7.5 A；150 W
    · DOS20-15：±20 V；±15 A；300 W
    · DOS20-30：±20 V；±30 A；600 W
    · DOS20-60：±20 V；±60 A；1200 W
    · DOS20-100：±20 V；±100 A；2000 W
    · DOS25-6：±25 V；±6 A；150 W
    · DOS25-12：±25 V；±12 A；300 W
    · DOS25-24：±25 V；±24 A；600 W
    · DOS25-48：±25 V；±48 A；1200 W
    · DOS25-80：±25 V；±80 A；2000 W
    · DOS45-3.3：±45 V；±3.3 A；150 W
    · DOS45-6.6：±45 V；±6.6 A；300 W
    · DOS45-13.3：±45 V；±13.3 A；600 W
    · DOS45-16：±45 V；±16 A；720 W
    · DOS45-26.7：±45 V；±26.7 A；1200 W
    · DOS45-44.4：±45 V；±44.4 A；2000 W
    · DOS60-2.5：±60 V；±2.5 A；150 W
    · DOS60-5：±60 V；±5 A；300 W
    · DOS60-10：±60 V；±10 A；600 W
    · DOS60-20：±60 V；±20 A；1200 W
    · DOS60-33.3：±60 V；±33.3 A；2000 W
    以上指标摘自厂商官方网站产品页/公开技术资料；厂商未标注测试条件与典型值口径的条目均按原文收录，实际以厂商正式规格书为准。
    资源下载
    Matsusada Precision Inc. · onetest 仪器资源库
    本文由 onetest 仪器资源库依据厂商公开资料整理，参数以厂商正式资料为准。

    全部



    松田精密官方渠道


    厂家联系方式

    公司：Matsusada Precision Inc.（松田精密株式会社）

    国际/日本：TEL +81-6-6150-5088　FAX +81-6-6150-5089

    美国（北卡罗来纳）：TEL (704) 496-2644　FAX (704) 496-2643
