完整技术指标
Key features
· IFOV with standard lens (spatial resolution)：1.85 mRad, D:S 532:1
· Detector resolution：320 x 240
· SuperResolution：No
· Infrared Resolution：76, 800 pixels
· MultiSharp Focus：No
· LaserSharp Auto Focus：Yes, for consistently in-focus images
· Laser distance meter
– Yes, calculates distance to the target for precisely focused images and displays distance on screen
· Advanced manual focus：Yes
· Ruggedized touchscreen display：3.5 inch (landscape) 640 x 480 LCD
· Rugged, ergonomic design for one-handed use：Yes
· Digital zoom：No
Temperature measurement
· Temperature measurement range (not calibrated below -10 °C)：-20 °C to 650 °C (-4 °F to 1202 °F)
· Accuracy
– ±2 °C or 2% (at 25 °C nominal, whichever is greater)
· Thermal sensitivity (NETD)*：≤ 0.075 °C at 30 °C target temp (75 mK)
· On-screen emissivity correction：Yes (both value and table)
· On-screen reflected background temperature compensation：Yes
· On-screen transmission correction：Yes
Wireless connectivity
· Fluke Connect app compatible
– Yes*, connect your camera to your smartphone, and images taken automatically upload to the Fluke Connect app for saving and sharing
· Fluke Connect Assets optional software
– Through the desktop, assign images to assets, easily compare measurement types in one location and create reports
· Fluke Connect Instant Upload
– Yes*, connect your camera to your building’s WiFi network, and images taken automatically upload to the Fluke Connect system for viewing on your smartphone or PC
· Fluke Connect tool compatible
– Yes*, connects wirelessly to select Fluke Connect enabled tools and displays measurements on camera screen
Adds the context of the visible details to your infrared image
· Picture-In-Picture (PIP)：Yes
· Built-in digital camera (visible light)：5 MP
Lenses
· Standard lens IFOV (spatial resolution)：1.85 mRad, D:S 532:1
· Standard lens Field of view：34 °H x 24 °V
· Standard lens Minimum focus distance：15 cm (approx. 6 in)
· Standard lens IR-Fusion technology：Picture-In-Picture and full screen
· Optional 2x telephoto smart lens IFOV (spatial resolution)：0.93mRad, D:S 1529:1
· Optional 2x telephoto smart lens Field of view：17 °H x 12 °V
· Optional 2x telephoto smart lens Minimum focus distance：45 cm (approx. 18 in)
· Optional 2x telephoto smart lens IR-Fusion technology：Picture-In-Picture and full screen
· Optional 4x telephoto smart lens IFOV (spatial resolution)：0.46 mRad, D:S 2941:1
· Optional 4x telephoto smart lens Field of view：6 °H x 4.5 °V
· Optional 4x telephoto smart lens Minimum focus distance：1.5 m (approx. 60 in)
· Optional 4x telephoto smart lens IR-Fusion technology：N/A
· Optional wide-angle smart lens IFOV：2.62 mRad, D:S 377:1
· Optional wide-angle smart lens Field of view：48 °H x 34 °V
· Optional wide-angle smart lens Minimum focus distance：15 cm (approx. 6 in)
· Optional wide-angle smart lens IR-Fusion technology：Full screen
· Fast auto toggle between manual and auto modes：Yes
· Fast auto-rescale in manual mode：Yes
· Minimum span (in manual mode)：2.0 °C (3.6 °F)
· Minimum span (in auto mode)：3.0 °C (5.4 °F)
Data storage and image capture
· Extensive memory options
– Removable 4 GB micro SD memory card, 4 GB internal flash memory, save to USB flash drive capability, upload to Fluke Cloud for permanent storage
· Image file formats
– Non-radiometric (.bmp) or (.jpeg) or fully-radiometric (.is2); no analysis software required for non-radiometric (.bmp, .jpg and .avi) files
· Memory review：Thumbnail and fullscreen review
· Software
– Full analysis and reporting software with access to the Fluke Connect system
· Export file formats with SmartView software：Bitmap (.bmp), GIF, JPEG, PNG, TIFF
· Voice annotation
– 60 seconds maximum recording time per image; reviewable playback on camera, optional bluetooth headset available but not required
· IR-PhotoNotes：Yes (2 images)
· Text annotation：Yes
· Video recording：No
· File formats video：No
· Streaming video (remote display)：No remote display through Fluke Connect
· Remote control operation
– Remote display only through Fluke Connect with HDMI connection. No remote control.
· Auto capture (temperature and interval)：No
电池
· Battery life
– 2-3 hours per battery (*Actual life varies depending on settings and usage)
· Battery charge time：2.5 hours to full charge
· Battery charging system
– Two-bay battery charger or in-imager charging. Optional 12 V automotive charging adapter
· AC operation
– AC operation with included power supply (100 V AC to 240 V AC, 50/60 Hz)
· Power saving：User selectable sleep and power off modes
Color palettes
· Standard palettes
– 9: Rainbow, Ironbow, Blue-Red, High Contrast, Amber, Amber Inverted, Hot Metal, Grayscale, Grayscale Inverted
· Ultra Contrast palettes
– 9: Rainbow, Ironbow, Blue-Red, High Contrast, Amber, Amber Inverted, Hot Metal, Grayscale, Grayscale Inverted
一般规格
· Frame rate：60 Hz or 9 Hz versions
· Laser pointer：Yes
· LED light (torch)：Yes
· Color alarms (temperature alarms)
– High temperature, low temperature, and isotherms (within range)
· Center-point temperature measurement：Yes
· Spot temperature：Hot and cold spot markers
· User-definable spot markers：No
· Center box：No
· Infrared spectral band：7.5 μm to 14 μm (long wave)
· Operating temperature：-10 °C to +50 °C (14 °F to 122 °F)
· Storage temperature：-20 °C to +50 °C (-4 °F to 122 °F)
· Relative humidity：10% to 95% non-condensing
· Safety
– IEC 61010-1: Overvoltage category II, Pollution Degree 2
· Electromagnetic compatibility
– IEC 61326-1: Basic EM environment. CISPR 11: Group 1, Class A
· Australian RCM：IEC 61326-1
· US FCC：CFR 47, Part 15 Subpart B
· Vibration：0.03 g2/Hz (3.8 g), 2.5 g IEC 60068-2-6
· Shock：25 g, IEC 68-2-29
· Drop
– Engineered to withstand 2 meter (6.5 feet) drop with standard lens
· Size (H x W x L)：27.7 x 12.2 x 16.7 cm (10.9 x 4.8 x 6.5 in)
· Weight (battery included)：1.04 kg (2.3 lb)
· Enclosure rating
– IEC 60529: IP54 (protected against dust, limited ingress; protection against water spray from all directions)
