XR4 系列示波器，500 MHz，2 个模拟通道，混合信号并内置波形发生器
台式示波器
产品简介
4000 X 系列配备 12.1 英寸电容触摸屏、InfiniScan Zone 触控触发、每秒 100 万次波形更新率与 MegaZoom IV 智能存储技术，并标配分段存储。
核心参数
• 显示屏尺寸：12.1 inch
• 最大存储深度：4 Mpts
• 模拟通道数：2
• 数字通道数：16
• 最大采样率：5 GSa/s
• ADC 分辨率：8
• 含品牌：4000 Series
• 最大带宽：500 MHz
功能特性
• 产品亮点
500 MHz
2 个模拟通道加 16 个数字通道
在 12.1 英寸大尺寸电容触摸屏上轻松查看信号
借助独有的区域触摸触发功能，几秒内即可隔离信号
利用 4 Mpts 存储器和标配的分段存储器捕获更多数据
以 1,000,000 wfms/s 的更新速率查看更多信号细节
通过全面可升级性扩展测量能力：随时添加带宽、双通道 20 MHz 任意波形发生器、3 位数字电压表、串行触发与分析以及模板测试
包装内容：
嵌入式软件包（D4000GENB）
波形和测量直方图
双任意波形发生器
频率响应分析
KeysightCare 技术支持
3 年保修（非序列化附件如无源探头为 90 天）
校准证书，2 年校准周期
每个通道一支 N2894A 700 MHz 无源探头（10:1 衰减）
一条 N2756-60001 16 数字通道 MSO 电缆
本地化界面、前面板贴膜和内置帮助系统，支持英语、中文（简体和繁体）、法语、德语、意大利语、日语、韩语、葡萄牙语、俄语和西班牙语
本地化电源线
前面板盖
文档 CD，包含本地化用户指南、服务指南和程序员手册
免费下载 BenchVue Basic 应用以控制您的仪器
资源下载
以上内容与指标均取自是德科技（KEYSIGHT）官网该产品详情页与官方产品资料，未标注口径的为厂家公布值。
是德科技|KEYSIGHT · onetest 仪器资源库
是德科技 | KEYSIGHT
MSOX4052G 示波器 500MHz 详细指标
Benchtop Oscilloscopes
一、InfiniiVision 4000 X-Series Performance Specifications
DSO and MSO
4000A/G X-Series oscilloscopes
4000 X-Series specification overview
4022A/G 4024A/G 4032A/G 4034A/G 4052A/G 4054A/G 4104A/G
4154A/G
Bandwidth1 (–3 dB) 200 MHz 350 MHz 500 MHz 1 GHz
1.5 GHz2
All-channel real-time bandwidth 200 MHz 350 MHz 500 MHz 1 GHz
1 GHz
Calculated rise time (10 to 90%) ≤ 1.75 ns ≤ 1 ns ≤ 700 ps ≤ 450 ps ≤
300 ps
输入通道
条件：Display size and type 12.1-inch high-definition capacitive touch display
DSOX 2 4 2 4 2 4 4
4
MSOX 2 + 16 4 + 16 2 + 16 4 + 16 2 + 16 4 + 16 4 + 16 4 +
16
Maximum sample rate 5 GSa/s half channel
2.5 GSa/s all channel
Maximum memory depth 4 Mpts half channels
2 Mpts all channels
Waveform update rate >
1 million waveforms per second
System bandwidth with N2894A standard
passive probe 200 MHz 200 MHz 350 MHz 350 MHz 500 MHz 500 MHz 700 MHz
700 MHz
系统 analog 通道
Hardware bandwidth limits Approximately
20 MHz (selectable)
输入耦合 AC, DC
条件：1. Denotes warranted specifications, all others are typical. Specifications are valid after a 30- minute warm -up period and
2. 1.5 GHz real time bandwidth in half -channel mode or full channel equivalent time mode.
3. 1 mV/div and 2 mV/div is a magnification of 4 mV/div setting. For vertical accuracy calculations, use full scale of 32 mV
Input impedance Selectable: 1 MΩ ± 1% (16 pF), 50 Ω
± 1.5%
Input sensitivity range 200 MHz ~ 500 MHz models
1 mV/div to 5 V/div3 (1 MΩ and 50 Ω)
1 and 1.5 GHz models: 1 mV/div to 5 V/div3 (1 MΩ)
1 mV/div to 1 V/div (50 Ω)
Vertical resolution 8 bits (measurement resolution is
12 bits with averaging)
Maximum input voltage 1 MΩ
135 Vrms
Probing technology allows testing of higher voltages. For example, the included N2894A
10:1
probe supports testing up to 300 Vrms
Use this instrument only for measurements within its specified measurement category (not rated
for CAT II, III, IV). No transient overvoltage allowed 50 Ω 50 Ω: ≤
5 Vrms max
Trigger In 300 Vrms, mains isolated voltages only (No Measurement Category Allowed)
DC vertical gain accuracy1
± 2.0% full scale2
DC vertical offset accuracy ± 0.1 div ± 2 mV
± 1% of offset setting
Channel-to-channel isolation 200 MHz~1 GHz ≥
40 dB from DC to maximum specified bandwidth of each mode
1.5 GHz ≥ 40 dB from DC to 1 GHz, ≥
35 dB from 1 to 1.5 GHz
Offset range ± 5 V (< 10 mV/div), ± 20 V (10 to 200 mV/div), ± 75 V (>
200 mV/div)
± 10 °C from firmware calibration.
for 1 mV/div and 2 mV/div sensitivity setting.
Vertical 系统数字通道
Digital input channels 16 digital (D0 to D15. Pod 1: D7 ~ D0, Pod
2: D15 ~ D8)
Thresholds Threshold per pod
Threshold selections TTL (+1.4 V)
5 V CMOS (+2.5 V), ECL (–1.3 V), user-defined (selectable by pod)
User-defined threshold range
± 8.0 V in 10 mV steps
Maximum input voltage
± 40 V peak
Threshold accuracy1 ± (100 mV +
3% of threshold setting)
Maximum input dynamic range
± 10 V about threshold
Minimum voltage swing
500 mVpp
Input impedance 100 kΩ
± 2% at probe tip
Input capacitance
~8 pF
Vertical resolution
1 bit
Horizontal system analog channels 4022A/G 4024A/G 4032A/G 4034A/G 4052A/G 4054A/G 4104A/G
4154A/G
Time base range 2 ns/div to 50 s/div 1 ns/div to 50 s/div
500 ps/div to 50 s/div
Time base accuracy1
± 10 ppm
Time base delay time range Pre-trigger Greater of 1 screen width or 200 μs (400 μs in interleaving mode)
Post-trigger
1 to 500 s
Channel-to-channel deskew range
± 100 ns
Δ Time accuracy (using cursors) ± 0.001% of reading ± 0.16% screen width
± 30pS
On channels 1 and 2 only. Z Blanking on Ext Trigger Input
1.4 V threshold
Bandwidth: Maximum bandwidth. Phase error at 1 MHz: < 0.5 degree Time base
200 ns/div to
50 ms/div
Horizontal 系统数字通道
条件：1. Denotes warranted specifications, all others are typical. Specifications are valid after a 30- minute warm -up period
Minimum detectable pulse width
2 ns
Channel-to-channel skew 2 ns (typical)
3 ns (maximum)
Acquisition system 4022A/G 4024A/G 4032A/G 4034A/G 4052A/G 4054A/G 4104A/G
4154A/G
Maximum analog channels sample rate 5 GSa/s half channel interleaved
2.5 GSa/s all channels
Analog channels equivalent sample rate N/A
128 GSa/s
Maximum analog channels record length 4 Mpts half channel interleaved
2 Mpts all channel
Maximum digital channels sample rate
1.25 GSa/s
and
± 10 °C from firmware calibration.
Acquisition system 4022A/G 4024A/G 4032A/G 4034A/G 4052A/G 4054A/G 4104A/G
4154A/G
模式正常 Default 模式
Peak detect Capture glitches as narrow as
200 ps at all time base settings
Averaging Selectable from 2, 4, 8, 16
64, ... to 65,536
High resolution Real-time boxcar averaging reduces random noise and effectively increases vertical resolution
• 12 bits: ≥
50 μs/div
• 11 bits: ≥
20 μs/div
• 10 bits: ≥
10 μs/div
• 9 bits: ≥
5 μs/div
Segmented Segmented memory optimizes available memory for data streams that have long dead times
between activity. Maximum segments = 1000. Re-arm time =
1 μs (minimum time between
trigger events). Re-arm time when used with the zone touch trigger =
65 μs or faster (typical)
Roll Displays the waveform moving across the screen from right to left. Available at the time base
50 ms/div or slower
Digitizer Allows independent selection of sample rate and memory depth
Equivalent time 1 GHz and 1.5 GHz models only.
7.8 ps fine interpolator resolution yields a maximum effective
sample rate of 128 GSa/s
触发系统
Trigger sources Analog channel (1 ~ 4), digital channel (D0 ~ D15), line, external, WaveGen (1
2, or Mod)
Trigger modes Normal Requires trigger event for oscilloscope to trigger
Auto Triggers automatically in absence of trigger event
Single Front panel button that triggers only once on a trigger event. Press [Single] button again for
oscilloscope to find another trigger event, or press [Run] front-panel button to trigger
触发耦合 DC DC 耦合触发
条件：1. Denotes warranted specifications, all others are typical. Specifications are valid after a 30- minute warm -up period
AC AC coupled trigger, cutoff frequency: < 10 Hz (internal); <
50 Hz (external)
HF reject High-frequency reject, cutoff frequency ~
50 kHz
LF reject Low-frequency reject, cutoff frequency ~
50 kHz
Noise reject Adds hysteresis to the trigger circuitry. Selectable OFF or ON, decreases sensitivity
2x
Trigger holdoff range
40 ns to 10.00 s
Trigger sensitivity (internal)1 200 MHz ~ 1 GHz < 10 mV/div: greater of 1 div or 5 mV; ≥ 10 mV/div
0.6 di
1.5 GHz DC to 1 GHz: < 10 mV/div: Greater of 1 div or 5 mV; ≥ 10 mV/div
0.6 div
1 to 1.5 GHz: < 10 mV/div: Greater of 1.5 div or 5 mV; ≥ 10 mV/div
1.0 div
Trigger sensitivity (external)1 ± 1.6 V 40 mVpp DC to 100 MHz, 70 mVpp
100 to 200 MHz
± 8 V 200 mVpp DC to 100 MHz, 350 mVpp
100 to 200 MHz
Trigger level range Any channel
± 6 div from center screen
External 8 V range = ± 8 V, 1.6 V range =
± 1.6 V
and
± 10 °C from firmware calibration.
Supported 模式: 正常, 峰值 detect, 高分辨率
条件：Edge Trigger on a rising, falling, alternating, or either edge of analog channels, digital channels, or an external signal.
Also works simultaneously with the serial decodes and mask limit test.
触发开 rising 或 falling line 信号
条件：Edge then edge (B trigger) Arm on a selected edge, wait a specified time, then trigger on a specified count of another selected edge.
Minimum
4 ns
Pulse width Trigger on a pulse on a selected channel, whose time duration is less than a value, greater than a value, or inside
时间范围
• Minimum duration setting: 2 ns (500 MHz, 1 GHz, 1.5 GHz), 4 ns (350 MHz)
6 ns (200 MHz)
• Maximum duration setting
10 s
• Range minimum
10 ns
Pattern Trigger when a specified pattern of high, low, and don’t-care levels on any combination of analog, digital, or
trigger channels is [entered | exited]. Pattern must have stabilized for a minimum of 2 ns to qualify as a valid
trigger condition
• Minimum duration setting: 2 ns (500 MHz, 1 GHz, 1.5 GHz), 4 ns (350 MHz)
6 ns (200 MHz)
• Maximum duration setting
10 s
Or Trigger on any selected edges from available sources (analog and digital channels only up to 500 MHz)
Rise/fall time Trigger on rise-time or fall-time edge speed violations (< or >) based on user-selectable threshold. Select from (<
或 >) 和时间设置范围 between
• Minimum: 1 ns (500 MHz, 1 GHz, 1.5 GHz model), 2 ns (350 MHz model)
3 ns (200 MHz model)
• Maximum
10 s
Nth edge burst Trigger on the Nth (1 to 65535) edge of a pulse burst. Specify idle time (10 ns to 10 s) for framing
Runt Trigger on a positive runt pulse that fails to exceed a high-level threshold. Trigger on a negative runt pulse that
fails to exceed a low-level threshold. Trigger on either polarity runt pulse based on two threshold settings. Runt
triggering can also be time-qualified (< or >) with a minimum time setting of 2 ~
6 ns and maximum time setting of
10 s
• Minimum time setting: 2 ns (500 MHz, 1 GHz, 1.5 GHz), 4 ns (350 MHz)
6 ns (200 MHz)
Setup and hold Trigger on setup/hold violations. Setup time can be set from –7 to 10 s. Hold time can be set from 0 s to
10 ns. Minimum window (setup time + hold time) must be
3 ns or greater
Video Trigger on all lines or individual lines, odd/even or all fields from composite video, or broadcast standards (NTSC,
PAL, SECAM, PAM-M)
条件：conditions (parity, word, gap, word or gap, all), all bits (eye), all 0 bits, all 1 bits
FlexRay (Option) Trigger on frame ID or specific error condition, along with cycle-base and repetition-cycle filtering. Can also
I²C (Option) Trigger at a start/stop condition or user defined frame with address and/or data values. Also trigger on missing
Enhanced video (HDTV) (Option) Trigger on lines and fields of enhanced and HDTV standards (480p/60, 567p/50, 720p/50, 720p/60
1080p/24
1080p/25, 1080p/30, 1080p/50, 1080p/60, 1080i/50
1080i/60)
ARINC429 (Option) Trigger and decode on ARINC429 data. Trigger on word start/stop, label, label + bits, label range, error
CAN (Option) Trigger on CAN (controller area network) version
2.0A,2.0B, and CAN-FD (Flexible Data-rate) signals. Trigger on
the start of frame (SOF), the end of frame (EOF), data frame ID, data frame ID and data (non-FD), data frame ID
and data (FD), remote frame ID, remote or data frame ID, error frame, acknowledge error, from error, stuff error,
CRC error, spec error (ack or form or stuff or CRC), all errors, BRS Bit (FD), CRC delimiter bit (FD), ESI bit active
(FD), ESI bit passive (FD), overload frame., message, message and signal (non-FD), message and signal (FD,
first
8 bytes only)
trigger on specific events such as BSS, TSS, FES, and wake up
acknowledge, address with no acq, restart, EEPROM read, and 10-bit write
I²S (Option) Trigger on
2’s complement data of audio left channel or right channel (=, ≠, <, >, > <, < >, increasing value, or
触发类型 selections
LIN (Option) Trigger on LIN (local interconnect network) sync break, sync frame ID, frame ID and data, parity error, or
checksum error
条件：error, data length error, sample error, all errors, sleep frame, wakeup pulse.
error conditions (parity, sync, Manchester)
CXPI (Option) Trigger on the start of frame (SOF), the end of frame (EOF), PTYPE, frame ID, data and info frame ID, data and
info frame ID (long frame), CRC field error, parity error, inter-byte space error, inter-frame space error, framing
MIL-STD1553 (Option) Trigger on MIL-STD 1553 signals on data word start/stop, command/status start/stop, RTA, RTA +
11 bits, and
SPI (Option) Trigger on SPI (serial peripheral interface) data pattern during a specific framing period. Supports positive and
negative chip select framing as well as clock Idle framing and user-specified number of bits per frame. Supports
MOSI and MISO data
UART/RS232/422/485 (Option) Trigger on Rx or Tx start bit, stop bit, data content, or parity error
USB (Option) Trigger on start of packet (SOP), end of packet (EOP), suspend1, resume1, reset1, packets (token, data,
handshake, or special), and errors (PID, CRC5, CRC16, glitch, bit stuff1, SE11). Supports USB
2.0 low speed, full
speed, and hi-speed (hi-speed is supported on
1 GHz and 1.5 GHz models only)
SENT (Option) Trigger on SENT bus. start of fast channel message, start of slow channel message, fast channel SC and data,
slow channel message ID, slow channel message ID and data, tolerance violation, fast channel CRC error, slow
channel CRC error, all CRC errors, pulse period error, successive sync pulses error (1/64)
User-definable Manchester/NRZ (Option)
Trigger on start-of-frame (SOF), bus value, and Manchester errors
USB PD (Option) Trigger on preamble, EDP, ordered sets, preamble errors, CRC errors, header content (control messages, data
波形测量和 cursors
条件：Automatic measurements Measurements continuously updated with statistics. Cursors track last selected measurement.
DC vertical accuracy/cursors2 Single cursor accuracy: ± [DC vertical gain accuracy + DC vertical offset accuracy +
0.21%
full scale] Dual cursor accuracy: + [DC vertical gain accuracy +
0.42% full scale]3
Cursors
2 pairs of XY cursors
Automatic measurement of positions, ∆X
1/∆X, ∆Y, and ∆Y/∆X
Select up to four measurements from the list below
Vertical “Y at X” Peak-to-peak, maximum, minimum, amplitude, top, base, overshoot, pre-shoot, average- N
cycles, average- full screen, DC RMS- N cycles, DC RMS- full screen, AC RMS- N cycles, AC
RMS- full screen (standard deviation), ratio (RMS1/RMS2)
Time at edge Period, frequency, counter, + width, - width, burst width, duty cycle, bit rate, rise time, fall time,
延迟, 相位, X · 最小 Y, X · 最大 Y
Count Positive pulse count, negative pulse count, rising edge count, falling edge count
Mixed slew rate Area- N cycles, area- full screen
条件：Automatic measurement logging Available via BenchVue 1. Suspend, resume, reset, bit stuff error, and SE1 error are USB 2.0 low and full speed only. 2. 1 mV/div and 2 mV/div is a magnification of 4 mV/div setting. For vertical accuracy calculations, use full scale of 32 mV for 1 mV/div and 2 mV/div sensitivity setting.
3. Denotes warranted specifications, all others are typical. Specifications are valid after a 30- minute warm -up period and
± 10 °C from firmware calibration temperature
源 Any analog 或数字通道
Resolution 5 digits. Up to 8 digits with an external reference
10 MHz input
最大频率带宽 oscilloscope
Mask limit test option Mask limit test capability that provides easy, fast pass/fail comparison of a signal under test to
a predefined mask template or auto-mask template. Predefined mask templates or edits to an
auto-mask template can be made via a simple text editor. >
270,000 mask tests per second
(波形 update 速率)
Measurement limit test (Option) Provide pass/fail analysis on selected parametric measurements based on user-defined
maximum and minimum limits with selectable stop-on-failure capability
编号 math 功能 Four (显示 one · 时间)
Arithmetic Add, subtract, multiply, divide, differentiate, integrate, FFT, Ax + B, squared, square root, absolute, common log,
natural log, exponential, base
10 exponential, LP filter, HP filter, averaged value, smoothing, envelope, magnify
max hold, min hold, measurement trend, chart logic bus (timing or state) , chart serial signal (CAN, CAN FD, LIN,
and SENT)
FFT Up to 64 kpts resolution. FFT window types: Hanning, flat top, rectangular, Blackman-Harris, Bartlett
二、显示规格
Display
12.1-inch capacitive touch/gesture enabled color TFT LCD
Resolution 800 (H) x
600 (V) pixel format (screen area)
Graticules 8 vertical divisions by
10 horizontal divisions with intensity controls
Format YT, XY and Roll
Maximum waveform update rate >
1,000,000 wfm/s
Persistence Off, infinite, variable persistence (100 ms to 60 s)
Intensity gradation
64 intensity levels
USB 2.0 hi-speed host port USB 2.0 hi-speed host ports x3, two front and one real panel. Supports memory devices, printers, keyboards and
USB 2.0 hi-speed device port One USB 2.0 hi-speed device port on rear panel. USB Test and Measurement Class (USBTMC) compatible
LAN port
10/100Base-T port on rear panel. LXI IPv6 extended function
Web remote control VNC Web interface (via major Web browsers)
Video out port SVGA out on rear panel. Connect oscilloscope display to an external monitor or projector
GPIB port An external GPIB-to-LAN interface is available from ICS.
10 MHz out/in BNC connector on the rear panel. Supported modes: Off
10 MHz out, or reference signal mode (10 MHz in)
Trigger out BNC connector on the rear panel. Supported modes: triggers, mask, waveform generator
1 sync pulse, and
waveform generator
2 sync pulse
Dual-channel WaveGen built-in function/arbitrary waveform generator (specifications are typical)
WaveGen 输出 Two (前面板-面板 BNC 连接器)
Both waveform generator outputs can be frequency tracked, amplitude tracked, or completely tracked.* A
generator’s output can be inverted to create a differential signal
Waveforms Sine, square, ramp, pulse, DC, noise, sine cardinal (sinc), exponential rise, exponential fall, cardiac, Gaussian
脉冲, 和 arbitrary
Modulation Modulation is available on channel 1 only. Modulation is not available when tracking mode is enabled. Modulation
types: AM, FM, FSK
Carrier waveforms: Sine, Ramp, Sine Cardinal, Exponential Rise, Exponential Fall, and Cardiac.Modulation
Modulation: Sine, Square, Ramp
Modulation frequency: 1 Hz to 20 kHz Depth
0% to 100%
Modulation: Sine, Square, Ramp
Modulation frequency
1 Hz to 20 kHz
Minimum carrier frequency
10 Hz
Deviation
1 Hz to carrier frequency or (2e12/carrier frequency), whichever is smaller
条件：1. Only the following combination of wave shapes can be frequency tracked or completely tracked:
1) Sine, ramp, sine cardinal, cardiac, and Gaussian pulse.
2) Square wave and pulse
3) Exponential rise and exponential fall.
4) Arbitrary
1. Full resolution is not available at output due to internal attenuator stepping.
2. Sinc cardiac and Gaussian pulse: ± 1.25 V into Hi -Z; ± 625 mV into 50 Ω.
Modulation
50% duty cycle square wave
FSK rate
1 Hz to 20 kHz
Hop frequency
2 x FSK rate to 10 MHz
Dual-channel WaveGen built-in function/arbitary waveform generator (specifications are typical)
Sine Frequency range
0.1 Hz to 20 MHz
Amplitude flatness
± 0.5 dB (relative to 1 kHz)
Harmonic distortion
–40 dBc
Spurious (non harmonics)
–40 dBc
Total harmonic distortion
1%
Square wave/pulse Frequency range
0.1 Hz to 10 MHz
Duty cycle
20 to 80%
Duty cycle resolution Larger of 1% or 10 ns
Rise/fall time
19 ns (10 to 90%)
Overshoot <
2%
Asymmetry (at 50% DC) ± 1%
± 5ns
Jitter (TIE RMS)
500 ps
Ramp/triangle wave Frequency range
0.1 Hz to 200 kHz
Linearity
1%
Variable symmetry
0 to 100%
Symmetry resolution
1%
Pulse Frequency range
0.1 Hz to 10 MHz
Pulse width
20 ns minimum
Pulse with resolution
10 ns
Edge time Fixed at 19 ns (not variable)
Overshoot <
2%
Noise Bandwidth
20 MHz typical
Sine cardinal (Sinc) Frequency range
0.1 Hz to 1.0 MHz
Exponential rise/fall Frequency range
0.1 Hz to 5.0 MHz
Cardiac Frequency range
0.1 Hz to 200.0 kHz
Gaussian pulse Frequency range
0.1 Hz to 5.0 MHz
Arbitrary Waveform length
1 to 8,192 points
Amplitude resolution
10 bits (including sign bit)1
Repetition rate
0.1 Hz to 12 MHz
Sample rate
100 MSa/s
Filter bandwidth
20 MHz
Frequency Sine wave and ramp accuracy 130 ppm (frequency <
10 kHz)
50 ppm (frequency >
10 kHz)
Square wave and pulse accuracy [50 + frequency/200] ppm (frequency <
25 kHz)
50 ppm (frequency ≥
25 kHz)
Resolution
0.1 Hz or 4 digits, whichever is larger
Amplitude Range: Minimum 20 mVpp if |offset| ≤
0.5 Vpp into Hi-Z2
10 mVpp if |offset| ≤ 0.5 Vpp into
50 Ω2
Range: Maximum 10 Vpp except, 9 Vpp if Sinc or Cardiac
7.5 Vpp if Gaussian pulse
into Hi-Z; 5 Vpp/4.5 Vpp into
50 Ω
Resolution
100 μV or 3 digits, whichever is higher
Accuracy 1.5% (frequency =
1 kHz)
Dual-channel WaveGen built-in function/arbitary waveform generator (specifications are typical)
DC offset Range ± 5 V into Hi-Z, except ± 4 V if sine wave
± 2.5 V if sinc, cardiac
or Gaussian pulse into Hi-Z ± 2.5 V into Hi-Z, except ± 2 V if sine wave, ± 1.25 V if sinc, cardiac, or Gaussian pulse into
50 Ω
Resolution Larger of 250 uV or 3 digits
Accuracy (waveform modes) ± 1.5% of offset setting ± 1% of amplitude
± 1 mV
Accuracy (DC mode) ± 1.5% of offset setting
± 3 mV
Main output Impedance
50 Ω typical
数字 voltmeter (规格典型值)
Source Analog channels only (1-4)
功能 ACrms, DC, DCrms, 频率
Resolution ACV/DCV
3 digits
Counter frequency
5.5 digits
Measuring rate
100 times/second
Autoranging Automatic adjustment of vertical amplification to maximize the dynamic range of measurements
Range meter Graphical display of most recent measurement, plus extrema over the previous
3 seconds
三、通用与环境规格
Power line consumption Maximum
120 W
Power voltage range 100 to 120 V, 50/60/400 Hz; 100 to 240 V
50/60 Hz
Environmental rating 0 to 50 °C
3000 m max
Maximum Relative Humidity (non-condensing)
95%RH up to 40 °C
From 40 °C to 50 °C, the maximum % Relative Humidity follows the line of constant dew point
Electromagnetic compatibility Meets EMC Directive (2004/108/EC), meets or exceeds IEC
61326-1:2005/EN
61326-1:2006 Group
1 Class A requirement
CISPR 11/EN
55011
IEC 61000-4-2/EN
61000-4-2
IEC 61000-4-3/EN
61000-4-3
IEC 61000-4-4/EN
61000-4-4
IEC 61000-4-5/EN
61000-4-5
IEC 61000-4-6/EN
61000-4-6
IEC 61000-4-11/EN
61000-4-11
Canada: ICES-001:2004
Australia/New Zealand: AS/NZS
Safety CAN/CSA-C22.2 No. 61010-1-12, UPD1: 2015, UPD2: 2016, AMD1: 2018, CAN/CSA-C22.2 No.
61010-2-030:18
UL Std. No. 61010-1 3rd Ed. (2018); UL Std. No.
61010-2-030-2nd Ed. (2018)
Vibration Meets IEC60068-2-6 and MIL-PRF-28800; class
3 random
Publication title Publication number
Power Software Package - Data Sheet
5992-3925EN
Automotive Software Package - Data Sheet
5992-3912EN
Embedded Software Package - Data Sheet
5992-3924EN
Aero Software Package - Data Sheet
5992-3910EN
USB Software Package - Data Sheet
5992-3920EN
Ultimate Bundle Software Package - Data Sheet
5992-3918EN
四、通用与环境规格
Shock Meets IEC 60068-2-27 and MIL-PRF-28800; class 3 random; (operating 30 g, ½ sine. 11 ms duration
3 shocks/
axis along major axis, total of 18 shocks)
Dimensions (W x H x D) 454 mm x 275 mm x
156 mm
Weight Net: 6.3 kg (13.9 lbs), shipping
11.4 kg (25 lbs)
Kensington style lock Rear-panel security slot connects to standard Kensington-style lock
Nonvolatile storage
Reference waveform display
4 internal waveforms or USB thumb drive
Save formats Setup (*.scp), 8- or 24-bit bitmap image (*.bmp), PNG
24-bit image (*.png), CSV data (*.csv), ASCII XY data
(*.csv), binary data (*.bin), lister data (*.csv), reference waveform data (*.h5), multi-channel waveform data (*.h5),
mask (*.mask), arbitrary waveform data (*.csv), power harmonics data (*.csv), USB signal quality (*.html & *.bmp)
Max USB flash drive size Supports industry-standard flash drives
Set ups without USB flash drive
10 internal setups
Included standard with oscilloscope
Calibration Soft copy of Certificate of Calibration (CoC) with measurement results downloadable from
Probes One per channel N2894A
700 MHz passive probe (10:1 attenuation)
N2756A 16-digital-channel MSO cable (1 per oscilloscope included on all MSO models and DSOXPERFMSO)
Localized interface English, Chinese (simplified and traditional), French, German, Italian, Japanese, Korean, Portuguese, Russian,
Spanish localized front panel overlays, interface, and built-in help system
型号编号说明类型
DSOX4WAVEGEN2
Opt 开型号)
Built-in
20 MHz
License only
DSOXPERFMSO MSO upgrade: Add
16
cable delivered separately
DSOX4SECA Enhanced Security option License only
Publication title Publication number
D4000GENB Standard on G models, option on A models – Embedded Software Package: I2C, SPI, UART (RS232/422/485), I2S, and USB PD
serial trigger and decode, plus Measurement Limit Testing, Mask Limit Testing, Frequency Response Analysis (Bode plots), and
Enhanced Video Analysis
D4000AUTB Automotive Software Package: CAN, CAN FD, LIN, FlexRay, SENT, CXPI, PSI5 (User-definable Manchester), and User-definable
NRZ serial trigger & decode, plus Measurement Limit Testing, Mask Limit Testing and Frequency Response Analysis (Bode plots)
D4000AERB Aero Software Package: MIL-STD 1553 and ARINC 429 serial trigger and decode, plus Measurement Limit Testing, Mask Limit
Testing, Frequency Response Analysis (Bode plots), and Enhanced Video Analysis
D4000USBB1, 2 USB Software Package: USB 2.0 Low-, Full-, & Hi-speed, USB PD trigger & decode, plus USB
2.0 Signal Quality Test
Measurement Limit Testing, Mask Limit Testing, and Frequency Response Analysis (Bode plots)
D4000PWRB Power Software Package: Power quality, current harmonics, switching loss, turn-on/off time, transient response, loop response,
PSRR, & more, plus Measurement Limit Testing, Mask List Testing, Frequency Response Analysis (Bode plots), and USB PD
serial trigger & decode
D4000BDLB Ultimate Bundle Software Package: I2C, SPI, UART, I2S, CAN, CAN FD, LIN, FlexRay, CXPI, PSI5 (User-definable Manchester),
User-definable NRZ, USB 2.0 low-, full-, & hi-speed1, USB PD, MIL-STD 1553, and ARINC
429 serial trigger & decode, plus USB
2.0 Signal Quality Test2, Power Analysis, Measurement Limit Testing, Mask Limit Testing, Frequency Response Analysis (Bode
plots), Enhanced Video Analysis
条件：Process description 1 Place order for a license-only upgrade with a Keysight sales partner. 2 For software packages, you will receive a paper or electronic .pdf entitlement certificate. For bandwidth upgrades only, you will receive a stick-on label document indicating upgraded bandwidth specification in addition to a paper entitlement certificate.
oscilloscope model number and serial number unit. 4 Receive the licensed file and installation instructions via email. 5 Copy license file (.lic extension) from email to a USB drive and follow instructions in email to install the purchased bandwidth upgrade or measurement application on the oscilloscope.
3 Use entitlement certificate containing instructions and certificate number needed to generate a license file for a particular
4000 X-Series
6 For bandwidth upgrades only, attach bandwidth upgraded stick-on labels to front and rear panels of the oscilloscope. Model number and serial
number of the oscilloscope do not change
Return-to-Keysight Service Center Bandwidth Upgrades
4000 X-Series bandwidth upgrade models
型号编号说明类型
条件：specification. Model number and serial number of the oscilloscope do not change.
DSOX4B2T32U 200 MHz ~ 350 MHz
2 ch Service center
DSOX4B2T34U 200 MHz ~ 350 MHz
4 ch Service center
DSOX4B5T104U 500 MHz ~ 1 GHz
4 ch Service center
DSOX4B1T154U 1 GHz ~ 1.5 GHz
4 ch Service center
DSOX4B2T52U 200 MHz ~ 500 MHz
2 ch Service center
DSOX4B2T54U 200 MHz ~ 500 MHz
4 ch Service center
DSOX4B2T104U 200 MHz ~ 1 GHz
4 ch Service center
DSOX4B2T154U 200 MHz ~ 1.5 GHz
4 ch Service center
DSOX4B3T104U 350 MHz ~ 1 GHz
4 ch Service center
DSOX4B3T154U 350 MHz ~ 1.5 GHz
4 ch Service center
DSOX4B5T154U 500 MHz ~ 1.5 GHz
4 ch Service center
Process description 1 Place order for a return-to-Keysight service center bandwidth upgrade product to a Keysight sales partner. Serivce Center installation, calibration, shipment costs are in addition to bandwidth upgrade product price. 2 Keysight Business Center will contact you regarding process and timing of the service center installation. Continue to use oscilloscope until
contacted again later when parts are available at service center.
3 Ship the oscilloscope per provided instructions to service center.
4 Service center ships back upgraded oscilloscope with stick-on labels applied to front and rear panels indicating upgraded bandwidth
Confidently Covered by Keysight Services
Prevent delays caused by technical questions, or system downtime due to instrument maintenance and
repairs with Keysight Services. Keysight Services are here to support your test needs with expert
technical support, instrument repair and calibration, software support, training, alternative acquisition
以上指标摘自厂家官方数据手册，完整定义、测试条件与保证值口径以手册为准。完整指标、测试条件与定义口径请见产品页「软件和手册 | 白皮书」栏目中的官方数据手册。
是德科技 | KEYSIGHT · onetest 仪器资源库
全部
是德科技官方渠道
官方渠道（官网 / 热线 / 邮箱）
• 销售服务热线
800-810-0189（座机）／400-810-0189（手机） 工作时间 周一至周五 8:30-17:30
• 热线传真
800-820-2816（座机）／400-820-3863（手机）
• 亚洲区支持邮箱 tm_asia@keysight.com
• 服务与支持邮箱
instruments_services@keysight.com
• 官网
www.keysight.com（中国站 www.keysight.com.cn）
全国办事处
• 北京总部
是德科技（中国）有限公司 北京市朝阳区望京北路3号
电话：(010) 64397888
传真：(010) 64390278
邮编：100102
• 上海分公司
上海市虹口区四川北路1350号中信泰富申虹广场5楼、16-19楼
电话：(021) 36127688
传真：(021) 36127188
邮编：200080
• 广州分公司
广州市天河北路233号中信广场66层07-08室
电话：(020) 38113988
传真：(020) 86695074
邮编：510613
• 深圳分公司
深圳市福田中心区福华一路六号免税商务大厦3楼
电话：(0755) 83079588
传真：(0755) 82763181
邮编：518048
• 成都分公司
成都高新区南部园区天府四街116号
电话：(028) 83108888
传真：(028) 85330830
邮编：610041
• 西安分公司
西安市碑林区南关正街88号长安国际大厦D座5/F
电话：(029) 88867770
传真：(029) 88861330
邮编：710068
• 中国香港
是德科技香港有限公司 中国香港北角电气道169号25楼
电话：(852) 31977777
传真：(852) 25069292 香港热线 800-938-693
• 维修 / 校准服务中心
中国大陆 北京 / 成都 / 苏州 服务热线 800-810-0189 / 400-810-0189
授权分销商
• 上海信果电子科技有限公司（上海）
上海市沪闵路8075号虹梅商务大厦6楼609室
邮编：200233
电话：021-64518399
传真：021-54560890
邮箱：jason.wu@signalgroup.com.tw
• 上海精测电子有限公司（上海）
上海市北京东路668号西楼15E
邮编：200001
电话：13916371522
传真：021-53086102
邮箱：yangzhen@jingce.com
• 北京东方中科集成科技股份有限公司（北京）
北京市海淀区复兴路69号院12号楼2层、7层 邮政编码：100039
邮编：100039
电话：400-650-5566
传真：010-68728001
邮箱：zhangzp@oimec.com.cn
官网：www.dfzk.com/br_keysight.html
• 北京千聚科技发展有限公司（北京）
北京市海淀区西三旗花园雪梨澳乡A区23-4号
邮编：100085
电话：010-82907162
邮箱：zhuqihui@qianjukeji.com.cn
• 北京金龙翌阳科技发展有限公司（北京）
北京市海淀区大柳树路17号富海大厦2001室
邮编：100086
电话：010-62167379/6213538
邮箱：zhy@yy17.com
官网：www.yy17.com
• 厦门同昌源电子有限公司（厦门）
厦门市湖里区悦华路215号综合楼二楼C单元
邮编：361000
电话：0592-5663715
传真：0592-2236795
邮箱：tcydz@xmtcy.com
• 合肥新普仪测科技有限公司（合肥）
安徽省合肥市长江路53号长江大厦1102室
邮编：230001
电话：+86(0551)65177518 ext:
传真：+86(0551)6260 7155
邮箱：hfsimple@mail.hf.ah.cn
• 品展国际贸易(上海)有限公司（上海）
上海外高桥保税区泰谷路18号1号楼1105A室
邮编：200003
电话：+86(0512) 6808 6023
传真：+86(0512) 6808 6025
邮箱：melody@chtek.com.tw
官网：chtek.com.tw
• 广州康祺科技发展有限公司（广州）
广州市天河区华强路1号珠控国际中心8层06单元
邮编：510623
电话：020-38295200
传真：020-38295122
邮箱：baobao@kontchi.com
• 广州科欣仪器有限公司（广州）
广州市黄埔区黄埔大道933号209室
邮编：510700
电话：86-20-38699788
传真：86-20-34395932
邮箱：cs@gzkexin.com.cn
• 成都安诚迅飞电子科技有限公司（成都）
成都市武侯区人民南路四段27号1栋1单元 24层3号
邮编：610041
电话：028-86027579
邮箱：jincai.he@ancentest.com
• 新亚制程（浙江）股份有限公司（深圳）
深圳市福田区中康路卓越城梅林中心广场（北区）一期1栋3楼
邮编：518035
电话：0755-23818536
传真：0755-23818625
邮箱：wangrongbin@sunyes.cn
• 无锡市邦达测量科技有限公司（无锡）
江苏省无锡市新区长江北路112号
邮编：214028
电话：0510-85258521 ext:
邮箱：bdyiqi@bdyiqi.com
• 武汉力德仪测科技有限公司（武汉）
武汉市光谷大道54号国际企业中心四期A座501室
邮编：430074
电话：027-85481090 ext:
邮箱：liuyang@leader-e.com
• 苏州工业园区贝奇仪器有限公司（苏州）
苏州工业园区通园路398号海逸大厦A402室
邮编：215006
电话：0512-62883832
邮箱：szbeiqi@szbeiqi.net
• 青岛鲁芯仪器有限公司（青岛）
青岛市福州北路135号鼎都1号写字楼328室
邮编：266007
电话：15953279543
传真：0532-80669058-830
邮箱：gaochangyuan@qdluxin.com
• Avnet Electronics Marketing（Phoenix）
2211 South 47th Street
邮编：85034
电话：+65 6289 9164
邮箱：Josephine.Cheong@avnet.com
官网：OnlineSupportAsia@Avnet.com
• RFMW, Ltd.（San Jose）
188 Martinvale Lane
邮编：95119
电话：#09-129
邮箱：sales@rfmw.asia
官网：www.rfmw.com
• 沈阳实拓科技有限公司（沈阳）
沈阳市和平区三好街35号8层
邮编：110004
电话：024-23843636
传真：024-23905232
邮箱：lf@shituokeji.cn
• 領先科儀有限公司（香港）
新界荃灣海盛路3號TML廣場21樓B5室
邮编：.
电话：852-31523600
传真：852-31523608
邮箱：allenma@advanceinst.com
租赁合作伙伴
• 深圳君鉴科技股份有限公司（深圳市）
光明街道观光路华强创意产业园3栋B座12楼光明新区
邮编：518107
电话：400-860-3035
邮箱：shichang@chrent.com
• 益莱储（北京）检测设备租赁有限公司（北京市）
来广营高科技产业园区4号楼3层301朝阳区
邮编：100102
电话：400-819-2800
邮箱：jim.chen@electrorent.com
• 北京东方中科集成科技股份有限公司科技租赁事业部（北京市）
北京市海淀区阜成路67号银都大厦12层
邮编：100142
电话：400-650-5566
传真：010-68728001
邮箱：wangml@oimec.com.cn
• 客而禧设备租赁（上海）有限公司（Shanghai）
徐汇区古美路1515号19号楼903室
邮编：201102
电话：021-54453166
邮箱：krc@krcchina.com
• 深圳市瑞普高电子有限公司（深圳市）
天安云谷产业园一期3栋D座1505-1506龙岗区
邮编：518129
电话：0755-29050100
邮箱：rickluo@ruipugao.com
• 苏州锦凡精密仪器科技有限公司（苏州）
苏州市高新区滨河路625号创业大厦5幢505
邮编：215011
电话：18914031336
邮箱：18914031336@jfsz.net
解决方案合作伙伴
• Tokyo Weld Co., Ltd.（Ota-ku）
2-28-1 Kitamagome
邮编：143-0021
电话：81-3-3775-4331
传真：81-3-3775-4359
邮箱：d-imai@tokyoweld.com
• 上海恒榉电子科技有限公司（Shanghai）
上海市奉贤区南桥镇西闸公路1036号3栋2层
邮编：201401
电话：18112779808
邮箱：salesvalue@everise-hj.com
• 佳燁科技股份有限公司(Ghiatek)（桃園市龜山區）
光明街243巷2號
邮编：33372
电话：+886-3-350-9960
传真：+886-3-320-3475
邮箱：support@ghiatek.com
• 华美博科技（北京）有限公司（北京市）
蓝靛厂东路2号金源时代商务中心C座9A2海淀区
邮编：100097
电话：010-88598732
邮箱：sino@sino-microtech.com
• 和创联合科技（北京）有限公司（北京市）
中关村东路18号财智国际大厦A座1612海淀区
邮编：100083
电话：400 650 7802
邮箱：info@hisuntest.com
• 昆山捷得立电子有限公司（昆山市）
登云路288号海创大厦C座25楼
邮编：215316
电话：0512-36831748
邮箱：sales@jiedeli-china.com
• 深圳市捷泰普科技有限公司（深圳市）
宝安区西乡街道前进二路桃源居南面深圳市智汇创新中心A座216室
邮编：518126
电话：0755-83908488
邮箱：sales@jtptech.cn
• 深圳市易捷测试技术有限公司（深圳市）
福虹路9号世贸广场C座1203室福田区
邮编：518033
电话：0755-83698930
邮箱：dongni.zhang@gbit.net.cn
官网：gbit.net.cn
• 深圳市泰仕捷科技有限公司（深圳市）
松岗大道7号汉海达大厦616室宝安区
邮编：518105
电话：0755-27128586
邮箱：riky.gua@tesijet.com
• 深圳市蓉声科技有限公司（深圳市）
福中路海连大厦连天阁 1103 室福田区
邮编：518033
电话：13828880571
邮箱：jiang.qian@radiation-test.com
• 苏州伊欧陆系统集成有限公司（苏州）
星湖街218号生物纳米园A7楼305室苏州工业园区
邮编：215000
电话：4008808776
邮箱：info@eoulu.com
• EM Labs Inc.（Kobe）
1-4-13 Mizukasadori, Nagata
邮编：653-0842
电话：+81-50-5370-0262
邮箱：info@emlabs.jp
• MPI Corporation（Chupei）
No. 155 Chungho Street
邮编：302
电话：+886-3-555-1771
传真：+886-3-551-8381
邮箱：info@mpi-corporation.com
官网：www.mpi-corporation.com/ast
• NOFFZ（Tönisvorst）
Vorster Strasse 238
邮编：47918
电话：+49 2151-99878-0
邮箱：info@noffz.com
• Power Technology Solutions（Santa Clara）
3048 Scott Blvd
邮编：95054
电话：650-308-8091 ext:
传真：408-727-0827
邮箱：inquiries@pwrts.com
• Resillion（Hasselt）
Kempische Steenweg 303
邮编：3500
电话：+32 498 92 01 71
邮箱：global-ci-sales@resillion.com
• Suzhou Link Ways Tech Co., Ltd.（Suzhou）
16F, Block B, Jin Shi Wang Hu Building, No. 18, Jia Rui alley, SIP
邮编：215021
电话：+86 512 6602 8998
• 上海凌测电子科技有限公司（上海）
峨山路91弄120号陆家嘴软件园8号楼401A室浦东新区
邮编：200127
电话：021-61090608
邮箱：yue.lin@merlintest.com.cn
• 上海北汇信息科技有限公司（上海市）
秀路100号虹桥总部1号4号楼3C闵行区紫
邮编：201103
电话：021-34716271
邮箱：info@polelink.com
官网：polelink.com
• 上海怿星电子科技有限公司（上海市）
钦州北路1199号智汇园87号楼5F室徐汇区
邮编：200233
电话：021-64955659
邮箱：biz@e-planet.cn
• 东昇电磁兼容技术(深圳)有限公司（深圳市）
福田中心区26-3路中国凤凰大厦2栋25G
邮编：518026
电话：0755-82792411
邮箱：sales@jstoyo.cn
• 南京派格测控科技有限公司（南京市）
建邺区建邺人才服务大厦16楼
邮编：210019
电话：4008920858
邮箱：sales@pgtec.cn
官网：pgtec.cn
• 南京纳特通信电子有限公司（南京市）
江宁开发区临淮街20号
邮编：210012
电话：025-84471796
邮箱：sales@rflight.cn
• 深圳市研辰科技有限公司（深圳市）
益田路3008号皇都广场C座2815室福田区
邮编：518048
电话：0755-82828703
邮箱：roger_huang@ascentest.com
原厂翻新与二手仪器
• 是德科技原厂二手仪器商城（Keysight Certified Pre-Owned）：www.keysight.com/used/cn/zh/
• 原厂翻新仪器经与新品相同的最终测试与校准，原厂保修最长 5 年；享 40%–90% 折扣，另有线上 5% / 教育 15% 优惠
0条提问
X
提问
X
回答
暂无视频
0条口碑
X
发表口碑
粤公网安备44030902003758
