    Matsusada Precision Inc. · 放大器

    DOA 高速双极性放大器

    Model ｜Maximum Output · Voltage；Current；Power · ±75 V；±1 A；75 W · ±2 A；150 W
    Model ｜Maximum Output
    Voltage；Current；Power
    ±75 V；±1 A；75 W
    DOA75-1
    ±2 A；150 W
    DOA75-2
    ±4 A；300 W
    DOA75-4
    ±150 V；±1 A；150 W
    DOA150-1
    产品定位

    The DOA series is a four-quadrant bipolar amplifier featuring wide bandwidth and ultra-high-speed response from DC to 1 MHz. It is ideal for transient response testing,

    effectively utilizing its high-speed characteristics. Capable of operating as both a DC power supply and an electronic load,

    it can drive various loads, including inductive loads such as transformers,

    capacitive loads such as capacitors,

    and piezoelectric elements. This versatile series delivers maximum current even at DC output.

    Note: This product is not designed for charge and discharge of battery. For battery charging and discharging applications,

    please refer to the Battery Cycle Tester product page.

    核心参数
    · ：Model ｜Maximum Output
    · ：Voltage；Current；Power
    · DOA75-1：±75 V；±1 A；75 W
    · DOA75-2：±2 A；150 W
    · DOA75-4：±4 A；300 W
    · DOA150-1：±150 V；±1 A；150 W
    · DOA150-2：±2 A；300 W
    ·
    – Standard ｜CABLE TYPE1 ｜125 V/10 A ｜2.5 meters Fixed length
    · Sold separately
    – CABLE TYPE3
    – 250 V/10 A
    – 2.5 meters Fixed length
    · Sold separately
    – CABLE TYPE4
    – 250 V/10 A
    – 2.5 meters Fixed length
    功能与特点
    · High-speed response of DC to 1 MHz or 500 kHz.
    · Four-quadrant operation capable of sourcing and sinking current.
    · Equipped with a DC bias function (DC offset voltage setting).
    · Capable of outputting maximum current at DC.
    · Reliable design featuring overvoltage, overcurrent, and output short-circuit protections.
    典型应用
    · 驱动放大
    资源下载
    · 本页仅列出核心参数，完整技术指标请见 DOA-specs.html
    Matsusada Precision Inc. · onetest 仪器资源库
    本文由 onetest 仪器资源库依据厂商公开资料整理，参数以厂商正式资料为准。





    Matsusada Precision Inc. · 放大器

    DOA 高速双极性放大器 · 详细指标

    Model ｜Maximum Output · Voltage；Current；Power · ±75 V；±1 A；75 W · ±2 A；150 W
    产品简介

    The DOA series is a four-quadrant bipolar amplifier featuring wide bandwidth and ultra-high-speed response from DC to 1 MHz. It is ideal for transient response testing,

    effectively utilizing its high-speed characteristics. Capable of operating as both a DC power supply and an electronic load,

    完整技术指标
    · ：Model ｜Maximum Output
    · ：Voltage；Current；Power
    · DOA75-1：±75 V；±1 A；75 W
    · DOA75-2：±2 A；150 W
    · DOA75-4：±4 A；300 W
    · DOA150-1：±150 V；±1 A；150 W
    · DOA150-2：±2 A；300 W
    ·
    – Standard ｜CABLE TYPE1 ｜125 V/10 A ｜2.5 meters Fixed length
    · Sold separately
    – CABLE TYPE3
    – 250 V/10 A
    – 2.5 meters Fixed length
    · Sold separately
    – CABLE TYPE4
    – 250 V/10 A
    – 2.5 meters Fixed length
    以上指标摘自厂商官方网站产品页/公开技术资料；厂商未标注测试条件与典型值口径的条目均按原文收录，实际以厂商正式规格书为准。
