    Matsusada Precision Inc. · 放大器

    DOL 高速双极性放大器

    CABLE TYPE5；300V/25A
    产品定位

    The DOL series is a four-quadrant bipolar amplifier featuring fast response and high power output. It operates in both Constant Voltage (CV) and Constant Current (CC) modes. By utilizing an aluminum frame,

    the series achieves half the weight of conventional models. Designed with a focus on usability,

    the DOL series offers simple operation and quiet performance.

    Note: This product is not designed for the charge and discharge of a battery. For battery charging and discharging applications,

    please refer to the Battery Cycle Tester product page.

    核心参数
    ·
    – Model ｜Maximum output ｜Frequency response (-3 dB)
    · ：Voltage；Current；Power；at CV mode；at CC mode
    · DOL18-15：±18 V；±15 A；270 W；DC to 15 kHz；DC to 10 kHz
    · DOL40-8：±40 V；±8 A；320 W；DC to 15 kHz；DC to 10 kHz
    · DOL40-16：±40 V；±16 A；640 W；DC to 10 kHz；DC to 10 kHz
    · DOL60-5：±60 V；±5 A；300 W；DC to 15 kHz；DC to 10 kHz
    · DOL120-3：±120 V；±3 A；360 W；DC to 15 kHz；DC to 10 kHz
    ·
    – Standard up to 360 W model ｜CABLE TYPE2 ｜125V/15A
    · Standard more than 600 W model -L(220V) option：CABLE TYPE5；300V/25A
    典型应用
    · 信号放大
    资源下载
    · 本页仅列出核心参数，完整技术指标请见 DOL-specs.html
    Matsusada Precision Inc. · onetest 仪器资源库
    本文由 onetest 仪器资源库依据厂商公开资料整理，参数以厂商正式资料为准。





    Matsusada Precision Inc. · 放大器

    DOL 高速双极性放大器 · 详细指标

    CABLE TYPE5；300V/25A
    产品简介

    The DOL series is a four-quadrant bipolar amplifier featuring fast response and high power output. It operates in both Constant Voltage (CV) and Constant Current (CC) modes. By utilizing an aluminum frame,

    the series achieves half the weight of conventional models. Designed with a focus on usability,

    完整技术指标
    ·
    – Model ｜Maximum output ｜Frequency response (-3 dB)
    · ：Voltage；Current；Power；at CV mode；at CC mode
    · DOL18-15：±18 V；±15 A；270 W；DC to 15 kHz；DC to 10 kHz
    · DOL40-8：±40 V；±8 A；320 W；DC to 15 kHz；DC to 10 kHz
    · DOL40-16：±40 V；±16 A；640 W；DC to 10 kHz；DC to 10 kHz
    · DOL60-5：±60 V；±5 A；300 W；DC to 15 kHz；DC to 10 kHz
    · DOL120-3：±120 V；±3 A；360 W；DC to 15 kHz；DC to 10 kHz
    ·
    – Standard up to 360 W model ｜CABLE TYPE2 ｜125V/15A
    · Standard more than 600 W model -L(220V) option：CABLE TYPE5；300V/25A
    以上指标摘自厂商官方网站产品页/公开技术资料；厂商未标注测试条件与典型值口径的条目均按原文收录，实际以厂商正式规格书为准。
    资源下载
    Matsusada Precision Inc. · onetest 仪器资源库
    本文由 onetest 仪器资源库依据厂商公开资料整理，参数以厂商正式资料为准。

    全部



    松田精密官方渠道


    厂家联系方式

    公司：Matsusada Precision Inc.（松田精密株式会社）

    国际/日本：TEL +81-6-6150-5088　FAX +81-6-6150-5089

    美国（北卡罗来纳）：TEL (704) 496-2644　FAX (704) 496-2643
