    Matsusada Precision Inc. · 放大器

    DOM 高速双极性放大器

    产品定位

    The DOM series is a four-quadrant bipolar power supply featuring a high-efficiency switching design and power regeneration capability. Despite its high power output,

    the unit is housed in a compact chassis,

    made possible by our advanced switching technology. It offers four-quadrant operation capable of both sourcing and sinking current,

    making it ideal for the magnetization and smooth demagnetization of electromagnets. The user-friendly front panel allows for easy setting of output voltage and current.

    核心参数
    · ：Model ｜Output ｜Frequency bandwidth (-3 dB)
    ·
    – Voltage [V] (rms)
    – Current [A] (rms)
    – Power [kW]
    · DOM6-125
    – 0 to ±6 V (0 to ±4.2 V)
    – 0 to ±125 A (0 to ±87.5 A)
    – 0.75 kW
    – DC to 1 kHz (at low amplitude)
    · DOM10-75
    – 0 to ±10 V (0 to ±7 V)
    – 0 to ±75 A (0 to ±52.5 A)
    – 0.75 kW
    · DOM20-50
    – 0 to ±20 V (0 to ±14 V)；0 to ±50 A (0 to ±35 A)；1 kW
    · DOM50-20
    – 0 to ±50 V (0 to ±35 V)；0 to ±20 A (0 to ±14 A)；1 kW
    · DOM100-10
    – 0 to ±100 V (0 to ±70 V)；0 to ±10 A (0 to ±7 A)；1 kW
    典型应用
    · 信号放大
    资源下载
    · 本页仅列出核心参数，完整技术指标请见 DOM-specs.html
    Matsusada Precision Inc. · onetest 仪器资源库
    本文由 onetest 仪器资源库依据厂商公开资料整理，参数以厂商正式资料为准。





    Matsusada Precision Inc. · 放大器

    DOM 高速双极性放大器 · 详细指标

    产品简介

    The DOM series is a four-quadrant bipolar power supply featuring a high-efficiency switching design and power regeneration capability. Despite its high power output,

    the unit is housed in a compact chassis,

    完整技术指标
    · ：Model ｜Output ｜Frequency bandwidth (-3 dB)
    ·
    – Voltage [V] (rms)
    – Current [A] (rms)
    – Power [kW]
    · DOM6-125
    – 0 to ±6 V (0 to ±4.2 V)
    – 0 to ±125 A (0 to ±87.5 A)
    – 0.75 kW
    – DC to 1 kHz (at low amplitude)
    · DOM10-75
    – 0 to ±10 V (0 to ±7 V)
    – 0 to ±75 A (0 to ±52.5 A)
    – 0.75 kW
    · DOM20-50
    – 0 to ±20 V (0 to ±14 V)；0 to ±50 A (0 to ±35 A)；1 kW
    · DOM50-20
    – 0 to ±50 V (0 to ±35 V)；0 to ±20 A (0 to ±14 A)；1 kW
    · DOM100-10
    – 0 to ±100 V (0 to ±70 V)；0 to ±10 A (0 to ±7 A)；1 kW
    以上指标摘自厂商官方网站产品页/公开技术资料；厂商未标注测试条件与典型值口径的条目均按原文收录，实际以厂商正式规格书为准。
    资源下载
    Matsusada Precision Inc. · onetest 仪器资源库
    本文由 onetest 仪器资源库依据厂商公开资料整理，参数以厂商正式资料为准。

    全部



    松田精密官方渠道


    厂家联系方式

    公司：Matsusada Precision Inc.（松田精密株式会社）

    国际/日本：TEL +81-6-6150-5088　FAX +81-6-6150-5089

    美国（北卡罗来纳）：TEL (704) 496-2644　FAX (704) 496-2643
