    Matsusada Precision Inc. · 放大器

    DHOP 高速双极性放大器

    0 to ±60 V · 240 W
    产品定位

    The DHOP series is a four-quadrant bipolar amplifier capable of sourcing and sinking current. It operates in both Constant Voltage (CV) and Constant Current (CC) modes. Thanks to its proprietary design,

    the series achieves a compact and lightweight form factor,

    weighing only 7 kg with a width of 8.27 inches (210 mm). These ultra-compact,

    high-speed amplifiers generate output signals proportional to various input waveforms, including sine,

    triangle, sawtooth, and square waves. The DHOP series is ideal for evaluating solar panels,

    battery-powered instruments, and battery management ICs.

    Note: This product is not designed for battery charging and discharging cycles. For battery charging and discharging applications,

    please refer to the Battery Cycle Tester product page.

    核心参数
    ·
    – Model ｜Maximum output ｜Frequency response (-3dB)
    · ：Voltage；Current；Power
    · DHOP20-12
    – ±20 V；±12 A；240 W；CV mode: DC to 100 kHz CC mode: DC to 10 kHz
    · DHOP30-8：±30 V；±8 A；240 W
    · DHOP45-5：±45 V；±5 A；225 W
    · DHOP60-4：±60 V；±4 A；240 W
    Notice of POWER switch changes
    · ：Before ｜After
    · Push button switch：Rocker switch
    CV/CC setting selection
    典型应用
    · 驱动放大
    资源下载
    · 本页仅列出核心参数，完整技术指标请见 DHOP-specs.html
    Matsusada Precision Inc. · onetest 仪器资源库
    本文由 onetest 仪器资源库依据厂商公开资料整理，参数以厂商正式资料为准。





    Matsusada Precision Inc. · 放大器

    DHOP 高速双极性放大器 · 详细指标

    0 to ±60 V · 240 W
    产品简介

    The DHOP series is a four-quadrant bipolar amplifier capable of sourcing and sinking current. It operates in both Constant Voltage (CV) and Constant Current (CC) modes. Thanks to its proprietary design,

    the series achieves a compact and lightweight form factor,

    完整技术指标
    ·
    – Model ｜Maximum output ｜Frequency response (-3dB)
    · ：Voltage；Current；Power
    · DHOP20-12
    – ±20 V；±12 A；240 W；CV mode: DC to 100 kHz CC mode: DC to 10 kHz
    · DHOP30-8：±30 V；±8 A；240 W
    · DHOP45-5：±45 V；±5 A；225 W
    · DHOP60-4：±60 V；±4 A；240 W
    Notice of POWER switch changes
    · ：Before ｜After
    · Push button switch：Rocker switch
    CV/CC setting selection
    · ：In CV mode ｜In CC mode
    · Vcon：Output voltage；Output current
    · -10 V：-Rating；-Rating
    · 0 V：0 A
    · +10 V：+Rating；+Rating
    Use of BIAS
    · ：In CV mode ｜In CC mode
    · Scale：Output voltage；Output current
    · 000 (ccw)：-Rating；-Rating
    · 500：0 V；0 A
    · 1000 (cw)：+Rating；+Rating
    ·
    – Standard ｜CABLE TYPE1 ｜125 V/10 A ｜2.5 meters Fixed length
    · Sold separately
    – CABLE TYPE3
    – 250 V/10 A
    – 2.5 meters Fixed length
    · Sold separately
    – CABLE TYPE4
    – 250 V/10 A
    – 2.5 meters Fixed length
