    Matsusada Precision Inc. · 直流电源

    W 高压电源

    0.5 to 40 kV · 3 to 700 mA · 120 to 350 W
    0.5 to 40 kV
    输出电压
    3 to 700 mA
    输出电流
    120 to 350 W
    输出功率
    产品定位

    The W series is a compact,

    high-power high-voltage power supply module designed for chassis mounting. It is an ideal choice for applications such as Automatic Test Equipment (ATE),

    X-ray inspection systems, and capacitor charging. Standard features include remote control, voltage monitoring,

    and current monitoring.

    The series offers a wide range of output configurations,

    with voltage from 0.5 kV to 40 kV and power from 120 W to 350 W.

    核心参数
    120 W
    · W1-0.5P
    – Output voltage：0 to 0.5 kVdc
    – Output current：0 to 240 mA
    – Ripple：1 Vp-p
    · W1-1P
    – Output voltage：0 to 1 kVdc
    – Output current：0 to 120 mA
    – Ripple：2 Vp-p
    · W1-3P
    – Output voltage：0 to 3 kVdc
    – Output current：0 to 40 mA
    – Ripple：6 Vp-p
    · W1-5P
    – Output voltage：0 to 5 kVdc
    – Output current：0 to 24 mA
    – Ripple：10 Vp-p
    · W1-10P
    – Output voltage：0 to 10 kVdc
    – Output current：0 to 12 mA
    – Ripple：20 Vp-p
    · W1-20P
    – Output voltage：0 to 20 kVdc
    – Output current：0 to 6 mA
    – Ripple：40 Vp-p
    · W1-30P
    – Output voltage：0 to 30 kVdc
    – Output current：0 to 4 mA
    – Ripple：150 Vp-p
    · W1-33P
    – Output voltage：0 to 33 kVdc
    – Output current：0 to 3.5 mA
    – Ripple：165 Vp-p
    · W1-35P
    – Output voltage：0 to 35 kVdc
    – Output current：0 to 3.3 mA
    – Ripple：175 Vp-p
    功能与特点
    · Compact and lightweight design
    · Remote control and monitoring capabilities
    · Automatic crossover between Constant Voltage (CV) and Constant Current (CC) modes
    · High efficiency
    · Comprehensive protection against output short-circuits and arcs
    · Wide range of output voltages and currents available
    典型应用
    · 自动化测试
    · 器件供电
    资源下载
    · 本页仅列出核心参数，完整技术指标请见 W-specs.html
    Matsusada Precision Inc. · onetest 仪器资源库
    本文由 onetest 仪器资源库依据厂商公开资料整理，参数以厂商正式资料为准。





    Matsusada Precision Inc. · 直流电源

    W 高压电源 · 详细指标

    0.5 to 40 kV · 3 to 700 mA · 120 to 350 W
    产品简介

    The W series is a compact,

    high-power high-voltage power supply module designed for chassis mounting. It is an ideal choice for applications such as Automatic Test Equipment (ATE),

    完整技术指标
    120 W
    · W1-0.5P
    – Output voltage：0 to 0.5 kVdc
    – Output current：0 to 240 mA
    – Ripple：1 Vp-p
    · W1-1P
    – Output voltage：0 to 1 kVdc
    – Output current：0 to 120 mA
    – Ripple：2 Vp-p
    · W1-3P
    – Output voltage：0 to 3 kVdc
    – Output current：0 to 40 mA
    – Ripple：6 Vp-p
    · W1-5P
    – Output voltage：0 to 5 kVdc
    – Output current：0 to 24 mA
    – Ripple：10 Vp-p
    · W1-10P
    – Output voltage：0 to 10 kVdc
    – Output current：0 to 12 mA
    – Ripple：20 Vp-p
    · W1-20P
    – Output voltage：0 to 20 kVdc
    – Output current：0 to 6 mA
    – Ripple：40 Vp-p
    · W1-30P
    – Output voltage：0 to 30 kVdc
    – Output current：0 to 4 mA
    – Ripple：150 Vp-p
    · W1-33P
    – Output voltage：0 to 33 kVdc
    – Output current：0 to 3.5 mA
    – Ripple：165 Vp-p
    · W1-35P
    – Output voltage：0 to 35 kVdc
    – Output current：0 to 3.3 mA
    – Ripple：175 Vp-p
    · W1-40P
    – Output voltage：0 to 40 kVdc
    – Output current：0 to 3 mA
    – Ripple：200 Vp-p
    · W1-0.5N
    – Output voltage：0 to -0.5 kVdc
    – Output current：0 to 240 mA
    – Ripple：1 Vp-p
    · W1-1N
    – Output voltage：0 to -1 kVdc
    – Output current：0 to 120 mA
    – Ripple：2 Vp-p
    · W1-3N
    – Output voltage：0 to -3 kVdc
    – Output current：0 to 40 mA
    – Ripple：6 Vp-p
    · W1-5N
    – Output voltage：0 to -5 kVdc
    – Output current：0 to 24 mA
    – Ripple：10 Vp-p
    · W1-10N
    – Output voltage：0 to -10 kVdc
    – Output current：0 to 12 mA
    – Ripple：20 Vp-p
    · W1-20N
    – Output voltage：0 to -20 kVdc
    – Output current：0 to 6 mA
    – Ripple：40 Vp-p
    · W1-30N
    – Output voltage：0 to -30 kVdc
    – Output current：0 to 4 mA
    – Ripple：150 Vp-p
    · W1-33N
    – Output voltage：0 to -33 kVdc
    – Output current：0 to 3.5 mA
    – Ripple：165 Vp-p
    · W1-35N
    – Output voltage：0 to -35 kVdc
    – Output current：0 to 3.3 mA
    – Ripple：175 Vp-p
    · W1-40N
    – Output voltage：0 to -40 kVdc
    – Output current：0 to 3 mA
    – Ripple：200 Vp-p
    200 W
    · W2-0.5P
    – Output voltage [kVdc]：0 to 0.5 kVdc
    – Output current：0 to 400 mA
    – Ripple：2.5 Vp-p
    · W2-1P
    – Output voltage [kVdc]：0 to 1 kVdc
    – Output current：0 to 200 mA
    – Ripple：2 Vp-p
    · W2-3P
    – Output voltage [kVdc]：0 to 3 kVdc
    – Output current：0 to 67 mA
    – Ripple：6 Vp-p
    · W2-5P
    – Output voltage [kVdc]：0 to 5 kVdc
    – Output current：0 to 40 mA
    – Ripple：10 Vp-p
    · W2-10P
    – Output voltage [kVdc]：0 to 10 kVdc
    – Output current：0 to 20 mA
    – Ripple：20 Vp-p
    · W2-20P
    – Output voltage [kVdc]：0 to 20 kVdc
    – Output current：0 to 10 mA
    – Ripple：40 Vp-p
    · W2-30P
    – Output voltage [kVdc]：0 to 30 kVdc
    – Output current：0 to 6.7 mA
    – Ripple：150 Vp-p
    · W2-40P
    – Output voltage [kVdc]：0 to 40 kVdc
    – Output current：0 to 5 mA
    – Ripple：200 Vp-p
    · W2-0.5N
    – Output voltage [kVdc]：0 to -0.5 kVdc
    – Output current：0 to 400 mA
    – Ripple：2.5 Vp-p
    · W2-1N
    – Output voltage [kVdc]：0 to -1 kVdc
    – Output current：0 to 200 mA
    – Ripple：2 Vp-p
    · W2-3N
    – Output voltage [kVdc]：0 to -3 kVdc
    – Output current：0 to 67 mA
    – Ripple：6 Vp-p
    · W2-5N
    – Output voltage [kVdc]：0 to -5 kVdc
    – Output current：0 to 40 mA
    – Ripple：10 Vp-p
    · W2-10N
    – Output voltage [kVdc]：0 to -10 kVdc
    – Output current：0 to 20 mA
    – Ripple：20 Vp-p
    · W2-20N
    – Output voltage [kVdc]：0 to -20 kVdc
